3 ． Hardware setup

Jumpers and Connectors

This Chapter indicates the locations of jumpers, headers and connectors. Users may find useful information
related to hardware settings in this chapter.
Figure 3.1. Jumpers and I/O panel Orientation
GSPI-Q3700-LLVA User's Manual
