BEC BiPAC 6300VNPOZ User Manual

4g/lte voip wireless-n (vpn) broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BiPAC 6300VNP(O)Z
4G/LTE VoIP Wireless-N (VPN)
Broadband Router
User Manual
Version release: v1.00
Last revised:July 4, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 6300VNPOZ and is the answer not in the manual?

Questions and answers

Related Manuals for BEC BiPAC 6300VNPOZ

Summary of Contents for BEC BiPAC 6300VNPOZ

  • Page 1 BiPAC 6300VNP(O)Z 4G/LTE VoIP Wireless-N (VPN) Broadband Router User Manual Version release: v1.00 Last revised:July 4, 2014...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ............................1  Introduction to your Router ..........................1  Features & Specifications ..........................3  Hardware Specifications ........................... 6  Application Diagram ............................7  Chapter 2: Product Overview..........................8  Important Note for Using This Router......................8  Device Description............................9  Front Panel LEDs ............................9  Rear Panel Connectors ..........................11  Power Source..............................12  Cabling ................................13  Chapter 3: Basic Installation..........................14  Network Configuration – IPv4 ........................15  Configuring PC in Windows 7/8 (IPv4)......................
  • Page 3 Quick Start ..............................50  Configuration ..............................54  Interface Setup ............................54  Internet ..............................55  LAN................................64  Wireless ..............................68  Wireless MAC Filter ..........................78  Advanced Setup............................79  Firewall ..............................80  Routing..............................81  NAT ................................. 82  Static DNS ............................... 87  QoS................................88  IPSEC Setting (6300VNOZ only) ......................89  PPTP Server (6300VNOZ only) ......................100  PPTP Client (6300VNOZ only) .......................

  • Page 4: Chapter 1: Introduction

    Introduction Chapter 1: Introduction Introduction to your Router Congratulations on your purchase of the BiPAC 6300VNP(O)Z (4G/LTE VoIP Wireless (VPN) Broadband Router). This router is a compact and advanced broadband router that offers flexible and multiple Internet connection options, EWAN and embedded 4G/LTE interfaces, for home, SOHO, and office users to enjoy high-speed, high-level security Internet connection via cellular wireless and/or Ethernet WAN.
  • Page 5 Introduction Secure VPN Connections (BiPAC 6300VNOZ only) The BiPAC 6300VNOZ supports comprehensive and robust IPSec VPN (Virtual Private Network) protocols for business users to establish private encrypted tunnels over the public Internet to secure data transmission between headquarters and branch offices. It also supports VPN dial in from smart phones for secure remote Internet connection via your home broadband.

  • Page 6: Features & Specifications

    Introduction Features & Specifications • 4G/LTE for high speed mobile broadband connectivity • Gigabit Ethernet WAN (GbE WAN) for Cable/Fiber/xDSL high WAN throughput • Gigabit Ethernet LAN • IPv6 ready (IPv4/IPv6 dual stack) • Multiple wireless SSIDs with wireless guest access and client isolation •...
  • Page 7 Introduction • MLD snooping and MLD proxy Firewall • Built-in NAT Firewall • Stateful Packet Inspection (SPI) • DoS attack prevention including Land Attack, Ping of Death, etc • Access control • IP&MAC filter, URL Content Filter • Password protection for system management •...
  • Page 8 Introduction VoIP • Compliant with SIP standard (RFC3261) • Codec: G.729, G.726, G.711 A-Law, G.711 u-Law • DTMF Method: Inband, RFC 2833, SIP Info • Caller ID Generation: DTMF, FSK • Silence Suppression (VAD), Echo Cancellation • Call Waiting, Conference Call •...

  • Page 9: Hardware Specifications

    Introduction Hardware Specifications Physical interface • 4G LTE antenna: 2 external antennas • WLAN: 2 internal PIFA antennas • SIM card slot: SIM card slot (for the SIM card from Telco / ISP) for mobile broadband connectivity • VoIP phone port: 2 RJ-11 FXS phone ports to connect with 2 regular analog phones. •...

  • Page 10: Application Diagram

    Introduction Application Diagram BiPAC 6300VNP(O)Z is an all-in-one router, supporting 2 connection options (4/LTE and EWAN) to connect to the Internet. 4G/LTE router mode With an embedded 4G/LTE module, the router can be used to connect to high speed mobile fixed wireless connection.

  • Page 11: Chapter 2: Product Overview

    Product Overview Chapter 2: Product Overview Important Note for Using This Router  Do not use the router in high humidity or high temperature. Do not use the same power source for the BiPAC  6300VNP(O)Z on other equipment.  Do not open or repair the case yourself.

  • Page 12: Device Description

    Product Overview Device Description Front Panel LEDs STATUS DESCRIPTION Green System is up and ready Power Boot failure Green UPS is functional properly Orange UPS battery failure. Need to recharge or replace a new battery Orange blinking UPS AC power failure and battery functional properly Battery Device powered by the DC power adaptor BiPAC 6300VNP(O)Z is successfully connected with a broadband connection...
  • Page 13 Product Overview Green IP connected and traffic is passing through the device. IP request failed. Internet BiPAC 6300VNP(O)Z is either in bridged mode or WAN connection not present.   BiPAC 6300VNP(O)Z User Manual...

  • Page 14: Rear Panel Connectors

    Product Overview Rear Panel Connectors  PORT MEANING Screw the supplied Wi-Fi antennas onto the antenna connectors on both sides. Antenna Insert the mini SIM card (2FF) with the gold contact facing down. SIM Card Slot Push the mini SIM card (2FF) inwards to eject it Connect your analog phone to this port with a RJ-11 cable.

  • Page 15: Power Source

    Product Overview Power Source BIPAC 6300VNP(O)Z offers two kinds of power input, namely, DC power Adapter and DC UPS (or BBU). BIPAC 6300VNP(O)Z can take the advantage of UPS (Uninterruptible Power Supply) to keep working even if the power outage hit your router when the router in working in DC UPS mode. (A picture of the rear focusing on the power source) (A shot from the front panel, with second icon being identified as the Battery LED) How to switch between the two (2) power sources, DC power adaptor and external UPS battery...

  • Page 16: Cabling

    Product Overview Battery LED Definition:  Green LED: UPS AC power is working; UPS battery is also working well  Orange LED Only UPS AC power is working. Battery failure- need to change or recharge battery  Orange LED: UPS AC power failure; UPS battery is working Cabling One of the most common causes of problems is bad cabling.

  • Page 17: Chapter 3: Basic Installation

    Basic Installation Chapter 3: Basic Installation The router can be configured with your web browser. A web browser is included as a standard application in the following operating systems: Windows 98 / NT /2000 / XP / ME / 7 / Vista, Linux, Mac OS, etc.

  • Page 18: Network Configuration - Ipv4

    Basic Installation Network Configuration – IPv4 Configuring PC in Windows 7/8 (IPv4) Go to Start. Click on Control Panel. Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel.
  • Page 19 Basic Installation Select Internet Protocol Version 4 (TCP/IPv4) then click Properties.   BiPAC 6300VNP(O)Z User Manual...
  • Page 20 Basic Installation In the TCP/IPv4 properties window, select the Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.  ...

  • Page 21: Configuring Pc In Windows Vista (Ipv4)

    Basic Installation Configuring PC in Windows Vista (IPv4) Go to Start. Click on Network. Then click on Network and Sharing Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections on the left window pane.
  • Page 22 Basic Installation Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.

  • Page 23: Configuring Pc In Windows Xp (Ipv4)

    Basic Installation Configuring PC in Windows XP (IPv4) 1. Go to Start. Click on Control Panel. 2. Then click on Network and Internet. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.  ...
  • Page 24 Basic Installation 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration.   BiPAC 6300VNP(O)Z User Manual...

  • Page 25: Configuring Pc In Windows 2000 (Ipv4)

    Basic Installation Configuring PC in Windows 2000 (IPv4) 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.

  • Page 26: Configuring Pc In Windows 98/Me

    Basic Installation Configuring PC in Windows 98/ME 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP ->NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC.

  • Page 27: Configuring Pc In Windows Nt4.0

    Basic Installation Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 28: Network Configuration - Ipv6

    Basic Installation Network Configuration – IPv6 Configuring PC in Windows 7/8 (IPv6) Go to Start. Click on Control Panel. Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel.
  • Page 29 Basic Installation Select Internet Protocol Version 6 (TCP/IPv6) then click Properties. In the TCP/IPv6 properties window, select the Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.

  • Page 30: Configuring Pc In Windows Vista (Ipv6)

    Basic Installation Configuring PC in Windows Vista (IPv6) Go to Start. Click on Network. Then click on Network and Sharing Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections on the left window pane.
  • Page 31 Basic Installation Select Internet Protocol Version 6 (TCP/IPv6) then click Properties. In the TCP/IPv6 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.

  • Page 32: Configuring Pc In Windows Xp (Ipv6)

    Basic Installation Configuring PC in Windows XP (IPv6) IPv6 is supported by Windows XP, but you need to install it first. Please follow the steps to install IPv6: 1. On the Desktop, Click Start > Run, type cmd, then press Enter key in the keyboard, the following screen appears.

  • Page 33: Default Settings

    Basic Installation Default Settings Before configuring the router, you need to know the following default settings. Web Interface: (Username and Password) Username: admin Password: admin The default username and password are “admin” and “admin” respectively. If you ever forget the username/password to login to the router, you may press the RESET button up to 6 seconds then release it to restore the factory default settings.

  • Page 34: Information From Your Isp

    Basic Installation Information from Your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) what kind of service is provided such as EWAN ((Dynamic IP address, Static IP address, PPPoE, Bridge Mode). Gather the information as illustrated in the following table and keep it for reference. Username, Password, Service Name, and Domain Name System (DNS) IP address (it can be automatically assigned by PPPoE...

  • Page 35: Chapter 4: Device Configuration

    Device Configuration / Status Chapter 4: Device Configuration Login to your Device Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “Go”, a user name and password window prompt appears. The default username and password is “admin” and “admin” respectively for the Administrator. NOTE: This username / password may vary by different Internet Service Providers.
  • Page 36 Device Configuration / Status Once you have logged on to your BIPAC 6300VNP(O)Z via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which includes: Quick Start Section...

  • Page 37: Status

    Device Configuration / Status Status In this section, you can check the router working status, including Device Info, System Log, 3G Status, Statistics, DHCP Table, IPSEC Status, PPTP Status, L2TP Status, Disk Status, and VoIP Status.   BiPAC 6300VNP(O)Z User Manual...

  • Page 38: Device Info

    Device Configuration / Status Device Info It contains basic information of the device. Device Information Model Name: Name of the router for identification purpose. Firmware Version: Software version currently loaded in the router MAC Address: A unique number that identifies the router  ...
  • Page 39 Device Configuration / Status  IPv4: IP Address: LAN port IPv4 address. Subnet Mask: LAN port IP subnet mask. DHCPv4 Server: LAN port DHCP role - Enabled, Relay or Disabled.  IPv6: IP Address: LAN port IPv6 address. Prefix Length: The prefix length DHCPv6 Server: The DHCP status.

  • Page 40: System Log

    Device Configuration / Status System Log In system log, you can check the operations status and any glitches to the router. Refresh: Press this button to refresh the statistics.   BiPAC 6300VNP(O)Z User Manual...

  • Page 41: 3G/4G-Lte Status

    Device Configuration / Status 3G/4G-LTE Status This page contains 3G/4G-LTE connection information. Status: The current status of the 3G/4G-LTE connection. Signal Strength: The signal strength bar and dBm value indicates the current 3G/4G-LTE signal strength. The front panel 3G/4G-LTE Signal Strength LED indicates the signal strength as well. Signal Information: Shows important LTE signal parameters such as RSRP (Reference Signal Receiving Power), RSRQ (Reference Signal Receiving Quality), SINR (Signal to Interference plus Noise Ratio).
  • Page 42 Device Configuration / Status Refresh: Press this button to refresh the statistics.   BiPAC 6300VNP(O)Z User Manual...

  • Page 43: Statistics

    Device Configuration / Status Statistics  Ethernet Interface: List all available network interfaces in the router. You are currently checking on the physical status of the Ethernet port. Transmit Frames: This field displays the number of frames transmitted until the latest second. Transmit Multicast Frames: This field displays the number of multicast frames transmitted until the latest second.
  • Page 44 Device Configuration / Status  Wireless Interface: List all available network interfaces in the router. You are currently checking on the physical status of the Wireless. Transmit Frames: This field displays the number of frames transmitted until the latest second. Transmit Error Frames: This field displays the number of error frames transmitted until the latest second.
  • Page 45 Device Configuration / Status  EWAN Interface: List all available network interfaces in the router. You are currently checking on the physical status of the EWAN port. Transmit Frames: This field displays the total number of frames transmitted until the latest second. Transmit Multicast Frames: This field displays the total number of multicast frames transmitted till the latest second.
  • Page 46 Device Configuration / Status  3G/4G-LTE Take 3G/4G-LTE as an example to describe the following connection transmission information. Interface: List all available network interfaces in the router. You are currently checking on the physical status of 3G/4G-LTE interface. Transmit Frames of Current Connection: This field displays the total number of 3G/4G-LTE frames transmitted until the latest second for the current connection.
  • Page 47 Device Configuration / Status  3G/4G_LTE via USB port Take 3G/4G-LTE USB as an example to describe the following connection transmission information. Interface: List all available network interfaces in the router. You are currently checking on the physical status of 3G/4G-LTE interface. Transmit Frames of Current Connection: This field displays the total number of 3G/4G-LTE frames transmitted until the latest second for the current connection.

  • Page 48: Dhcp Table

    Device Configuration / Status DHCP Table DHCP table displays the devices connected to the router with clear information. #: The index identifying the connected devices. Host Name: Show the hostname of the PC. IP Address: The IP allocated to the device. MAC Address: The MAC of the connected device.

  • Page 49: Ipsec Status (6300Vnoz Only)

    Device Configuration / Status IPSEC Status (6300VNOZ only) #: The IPSec entry index number. Connection Name: User-defined IPSEC VPN connection name. Remote Gateway: The IP of the remote gateway. Local Address: The IP and netmask of local access range. Remote address: The IP and netmask of remote access range. Connected: Show the connecting status.

  • Page 50: Pptp Status (6300Vnoz Only)

    Device Configuration / Status PPTP Status (6300VNOZ only) PPTP Client User: Four users(sessions) for client sessions. Here shows the using user. Connection Name: Show user-defined PPTP VPN connection name. Active: Show if the tunnel is active for connection. Connection Type: Remote Access or LAN to LAN. Server IP: Show the IP of VPN Server.

  • Page 51: L2Tp Status(6300Vnoz Only)

    Device Configuration / Status L2TP Status(6300VNOZ only) Name: Display the user-defined L2TP connection name. Type: The VPN mode: dialin or dialout. Connect: The connecting status. Active: Show if the L2TP tunnel is active for connection. Username: The user assigned to client (dialout use) or the user set for client to connect in (dialin use).  ...

  • Page 52: Disk Status

    Device Configuration / Status Disk Status Partition: Display the USB storage partition. Disk Space (KB): Display the total storage space of the NAS in Kbytes unit. Free Space (KB): Display the available space in Kbytes unit. VoIP Status VoIP status gives you a directive picture on the registered VoIP accounts. Phone Number: The number you use to register in the Basic page of VoIP.

  • Page 53: Quick Start

    Device Configuration / Quick Start Quick Start This is a useful and easy utility to help you to setup the router quickly and to connect to your ISP (Internet Service Provider) with only a few steps. It will guide you step by step to setup time zone and WAN settings of your device.
  • Page 54 Device Configuration / Quick Start Step 3 – Wireless Set up your wireless connection if you want to connect to the Internet wirelessly on your PCs. Click NEXT to continue. Step 4 – ISP Connection Type Set up your Internet connection. 4.1 Select an appropriate WAN connection protocol then click NEXT to continue.
  • Page 55 Device Configuration / Quick Start Click Next to save changes. 4.2 If selected EWAN / PPPoE, please enter PPPoE account information provided by your ISP. Click NEXT to continue. Step 5 – Quick Start Completed The Setup Wizard has completed. Click on BACK to modify changes or mistakes. Click NEXT to save the current settings.
  • Page 56 Device Configuration / Quick Start Switch to Status > Device Info to view the status.   BiPAC 6300VNP(O)Z User Manual...

  • Page 57: Configuration

    Device Configuration / Interface Setup Configuration Click to access and configure the available features in the following: Interface Setup, Advanced Setup, VoIP, Access Management, and Maintenance. These functions are described in the following sections. Interface Setup Here are the features under Interface Setup: Internet, LAN, Wireless and Wireless MAC Filter.  ...

  • Page 58: Internet

    Device Configuration / Interface Setup Internet  EWAN(6300VNPZ only) Multi Service Service Index: The index marks the EWAN interface of different ISP type, ranging from 0-7. Service Summary: The overall service information.   BiPAC 6300VNP(O)Z User Manual...
  • Page 59 Device Configuration / Interface Setup Status: Select whether to enable the service. IPv4/IPv6 IP Version: Choose IPv4, IPv4/IPv6, IPv6 based on your environment. If you don’t know which one to choose from, please choose IPv4/IPv6 instead. ISP Connection Type: ISP: Select the encapsulation type your ISP uses. ...
  • Page 60 Device Configuration / Interface Setup device acts as a NAT router; while if you dial up with the account within your PC, the device will then work as a bridge forwarding the PPPoE information to the PPPoE server and send the response to your PC, thus your PC gets a WAN IP working in the internet.
  • Page 61 Device Configuration / Interface Setup (only when choose IPv4/IPv6 or just IPv6 in IP version field above): IPv6 options IPv6 Address: Type the WAN IPv6 address from your ISP. Obtain IPv6 DNS: Choose if you want to obtain DNS automatically. Primary/Secondary: if you choose Disable in the Obtain IPv6 DNS field, please type the exactly primary and secondary DNS.
  • Page 62 Device Configuration / Interface Setup  EWAN(6300VNOZ only) Status: Select whether to enable the service. IPv4/IPv6 IP Version: Choose IPv4, IPv4/IPv6, IPv6 based on your environment. If you don’t know which one to choose from, please choose IPv4/IPv6 instead.   BiPAC 6300VNP(O)Z User Manual...
  • Page 63 Device Configuration / Interface Setup ISP Connection Type: ISP: Select the encapsulation type your ISP uses.  Dynamic IP: Select this option if your ISP provides you an IP address automatically.  Static IP: Select this option to set static IP information. You will need to enter in the Connection type, IP address, subnet mask, and gateway address, provided to you by your ISP.
  • Page 64 Device Configuration / Interface Setup IPv4 Options Get IP Address: Choose Static or Dynamic Static IP Address: If Static is selected in the above field, please enter the specific IP address you get from ISP and the following IP subnet mask and gateway address. IP Subnet Mask: The default is 0.0.0.0.
  • Page 65 Device Configuration / Interface Setup  3G/4G-LTE or 3G/4G-LTE via USB Status: Choose Activated to enable the 3G/4G-LTE connection. Network Mode: There are 8 options of service standards: “Automatic”, “UMTS 3G only”, “GSM 2G Only”, “UMTS 3G Preferred”, “GSM 2G Preferred”, “GSM and UMTS Only”, “LTE Only”, “GSM, UMTS, LTE”.
  • Page 66 Device Configuration / Interface Setup NAT: Select this option to Disabled/Enable the NAT (Network Address Translation) function. Enable NAT to grant multiples devices in LAN to access to the Internet through a single WAN IP. When router’s Internet configuration is finished successfully, you can go to the Status to check connection information.

  • Page 67: Lan

    Device Configuration / Interface Setup A Local Area Network (LAN) is a shared communication system to which many computers are attached and is limited to the immediate area, usually the same building or floor of a building. IPv4 Parameters IP Address: Enter the IP address of Router in dotted decimal notation, for example, 192.168.1.254 (factory default).
  • Page 68 Device Configuration / Interface Setup Alias IP Subnet Mask: Specify a subnet mask on this virtual interface. IGMP Snooping: Select Activated to enable IGMP Snooping function, Without IGMP snooping, multicast traffic is treated in the same manner as broadcast traffic - that is, it is forwarded to all ports. With IGMP snooping, multicast traffic of a group is only forwarded to ports that have members of that group.
  • Page 69 Device Configuration / Interface Setup IP Address: Enter the specific IP. For example: 192.168.1.110. MAC Address: Enter the responding MAC. For example: 00:0A:F7:45:6D:ED When added, you can see the ones listed as showed below: IPv6 parameters The IPv6 address composes of two parts, thus, the prefix and the interface ID. Interface Address / Prefix Length: Enter a static LAN IPv6 address.
  • Page 70 Device Configuration / Interface Setup DHCPv6 Server Type: Select Stateless or Stateful. When DHCPv6 is enabled, this parameter is available.  Stateless: If selected, the PCs in LAN are configured through RA mode, thus, the PCs in LAN are configured through RA mode, to obtain the prefix message and generate an address using a combination of locally available information (MAC address) and information (prefix) advertised by routers, but they can obtain such information like DNS from DHCPv6 Server.

  • Page 71: Wireless

    Device Configuration / Interface Setup Wireless This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to the wired LAN.  ...
  • Page 72 Device Configuration / Interface Setup Access Point Settings Access Point: Default setting is set to Activated. If you want to close the wireless interface, select Deactivated. AP MAC Address: The MAC address of wireless AP. Wireless Mode: The default setting is 802.11b+g+n (Mixed mode). If you do not know or have both 11g and 11b devices in your network, then keep the default in mixed mode.
  • Page 73 Device Configuration / Interface Setup SSID: The SSID is the unique name of a wireless access point (AP) to be distinguished from another. For security propose, change the default wlan-ap to a unique ID name to the AP which is already built-in to the router’s wireless interface.
  • Page 74 Device Configuration / Interface Setup suggest you select OPENWEB. Key 1 to Key 4: Enter the key to encrypt wireless data. To allow encrypted data transmission, the WEP Encryption Key values on all wireless stations must be the same as the router. There are four keys for your selection.
  • Page 75 Device Configuration / Interface Setup   BiPAC 6300VNP(O)Z User Manual...
  • Page 76 Device Configuration / Interface Setup Wi-Fi Protected Setup (WPS) Example I: PIN Method: Configure AP as Registrar 1. Jot down the client’s Pin (e.g. 04640776). 2. Enter the Enrollee (Client) PIN code and then press Start WPS.   BiPAC 6300VNP(O)Z User Manual...
  • Page 77 Device Configuration / Interface Setup 3. Launch the wireless client’s WPS utility (e.g. Ralink Utility). Set the Config Mode as Enrollee, press the WPS button on the top bar, select the AP (e.g. Billion_AP) from the WPS AP List column. Then press the PIN button located on the middle left of the page to run the scan.
  • Page 78 Device Configuration / Interface Setup Wi-Fi Protected Setup (WPS) Example II: PIN Method: Configure AP as Enrollee 1. Jot down the WPS PIN (e.g. 03454435). Press Start WPS. 2. Launch the wireless client’s WPS utility (e.g. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code column then choose the correct AP (e.g.
  • Page 79 Device Configuration / Interface Setup 3. The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar (client). 4. Now to make sure that the setup is correctly done, cross check to see if the SSID and the security setting of the registrar setting match with the parameters found on both Wireless Configuration and Wireless Security Configuration page.
  • Page 80 Device Configuration / Interface Setup Wi-Fi Protected Setup (WPS) Example III: PBC Method: 1. Press the PBC radio button, Then Start WPS. 2. Launch the wireless client’s WPS Utility (e.g. Ralink Utility). Set the Config Mode as Enrollee. Then press the WPS button and choose the correct AP (e.g. Billion_AP) from the WPS AP List section before pressing the PBC button to run the scan.
