Set up the Hardware

1 Mount the module
the fan and the heatsink
to the base board
Connect the Base Board
2
1. Insert module first. 2. Follow the steps in the order
indicated in the image below. 3. Insert power last.
1 Set/check
jumpers
VSEL
2 Set/check
Dip-Switches
ON
1 2 3 4
Air Flow
3 SD Card –
already
inserted
Screw M2.5 x 14
Nut M2.5
Thermal Pad
Screw M2
