Creality CR-10 Smart User Manual page 25

Circuit Wiring
Cable Port1
Cable Port 1
Cable Port 2 Cable Port2
Fuse
Fuse
Power Input
Power Input
Y axis motor
Y axis motor
Hot Bed Power Output Bed Thermistor
Bed Thermistor
Hot Bed Power
Z1 axis motor Z2 axis motor
Z1 axis motor Z2 axis motor
Normal Fan Shutdown Module Y Limit switch
Normal Fan Shutdown Y Limit switch
Module
Storage Card Slot Storage Card
Slot
WIFI Port
Wi-Fi Port
Screen
Screen Interface
Interface
Reserved Port WIFI Reset
Reserved Port
Wi-Fi Reset
