4.2. GNSS Performance

The following table shows UC20 GNSS performance.
Table 22: GNSS Performance
Parameter
Sensitivity
(GNSS)
TTFF
(GNSS)
Accuracy
(GNSS)
NOTES
1. Tracking sensitivity: the lowest GPS signal value at the antenna port for which the module can keep
on positioning for 3 minutes.
2. Reacquisition sensitivity: the lowest GPS signal value at the antenna port for which the module can
fix position again within 3 minutes after loss of lock.
3. Cold start sensitivity: the lowest GPS signal value at the antenna port for which the module fixes
position within 3 minutes after executing cold start command.
UC20_Hardware_Design
