match shown in dotted line between module and processor.
Driving DTR to low level will wake up the module.

3.5.1.2. USB Application with Suspend Function

If application processor communicates with module via USB interface, and processor supports USB
suspend function, the following preconditions can let the module enter into the sleep mode.

Execute AT command AT+QSCLK=1 to enable the sleep mode.
 The processor's USB bus which is connected with the module USB interface enters into suspended
state.
The following figure shows the connection between the module and processor.
When the processor's USB bus returns to resume state, the module will be woken up.

3.5.1.3. USB Application without Suspend Function

If application processor communicates with module via USB interface, and processor does not support
USB suspend function, you should disconnect USB_VBUS with additional control circuit to let the module
enter into sleep mode.

Execute AT command AT+QSCLK=1 to enable the sleep mode.

Disconnect USB_VBUS.
UC20_Hardware_Design
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Module
USB_VBUS
USB_DP
USB_DM
AP_READY
RI
GND
Figure 4: USB Application with Suspend Function
Confidential / Released
UMTS/HSPA Module Series
UC20 Hardware Design
Processor
VDD
USB_DP
USB_DM
GPIO
EINT
GND
