3.4. Operating Modes

The table below briefly summarizes the various operating modes referred to in the following chapters.
Table 5: Overview of Operating Modes
Mode
Normal Operation
Minimum
Functionality
Mode
Airplane Mode
UC20_Hardware_Design
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Details
Software is active. The module has registered to the GSM network
GSM Idle
and is ready to send and receive data.
GSM connection is ongoing. In this mode, the power consumption
GSM Talk/Data is decided by the configuration of power control level (PCL),
dynamic DTX control and the working RF band.
The module is ready for GPRS data transfer, but no data transfer
GPRS Idle is going on. In this case, power consumption depends on network
setting and GPRS configuration.
There is GPRS data in transfer (PPP, TCP or UDP). In this mode,
GPRS Data power consumption is decided by the PCL, working RF band and
GPRS multi-slot configuration.
The module is ready for data transfer in EDGE mode, but no data
EDGE Idle is currently sent or received. In this case, power consumption
depends on network settings and EDGE configuration.
There is EDGE data in transfer (PPP, TCP or UDP). In this mode,
EDGE Data power consumption is decided by the PCL, working RF band and
EDGE multi-slot configuration.
Software is active. The module has registered to the UMTS
UMTS Idle
network and the module is ready to send and receive data.
UMTS connection is ongoing. In this mode, the power
UMTS
consumption is decided by network setting (e.g. TPC pattern) and
Talk/Data
data transfer rate.
Software is active. The module has registered to the HSPA
HSPA Idle
network and the module is ready to send and receive data.
HSPA data transfer is ongoing. In this mode, the power
HSPA Data consumption is decided by network setting (e.g. TPC pattern) and
data transfer rate.
AT+CFUN command can set the module entering into a minimum functionality mode
without removing the power supply. In this case, both RF function and USIM card will
be invalid.
AT+CFUN command and W_DISABLE# pin can set the module entering into
airplane mode. In this case, RF function will be invalid.
