Door Dimensions - Manusa Op. Visio L1H Installation Manual

DMJOIL101EN - v1

1.3 DOOR DIMENSIONS

1.3.1 Door width.
DET
DET 1.4.1
S2*
Safety distance depends on S as follows:
If S <250 S2 = 200 mm
If S ≥250 S2 = 500 mm
Fig. 1.2
Fig. 1.3
DET 1.4.1
1.4.2
Fig.
1.4
VISIO L1H OPERATOR - INSTALLATION MANUAL
AH
PL = (AH-Dt)/2
AT = PL/2 + Dt
AM = PL + Sp
AF = AH-PL
Fig.
DET 1.4.2
S1*
Safety distances depending on Frame:
For D20,T20,F20,R20,T35,D35
For E20
For I30
For C44
For S44
5
Opening width
Clear width
Overall operator width
Sliding leaf width
Fixed leaf width
1.2
S1 = 0mm
S1 = 50mm
S1 = 55mm
S1 = 105mm
S1 = 105mm
