ASSEMBLY

1. To use the assembly steps in this manual, first see the helpful tips below.
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you fi nish all assembly steps.
2. If there are shipping tubes (not shown) attached
to the rower, remove and discard the shipping
tubes and the hardware attaching them.
With the help of a second person, pull the
Rail (2) outward and rotate the Stabilizer (3)
downward.
• Assembly requires the following tool(s):
one Phillips screwdriver
one adjustable wrench
To avoid damaging parts, do not use power tools.
2
3
2
7
