Survey Pro Reference Manual

Repetition Shots

6XUYH\ 5HSHWLWLRQ
The Repetition Shots screen is used to perform side shots or traverse
shots using any number of repetitions.
Note: The sequence that the repetition shots are performed is
selected in the Repetition Settings screen (Page R-38).
6HWWLQJV : located at the top of the screen, is a shortcut
to the Surveying and Repetition Settings screens (Page
R-34 and R-38 respectively).
Foresight: is the name of the point that will be stored.
Number of Sets: is the desired number of sets to shoot to
the backsight and foresight.
Note: One set is equivalent to two shots to the backsight
and foresight point.
HR: is the rod height.
Average (of): shows the average angle or distance to the
foresight from all the shots taken. The value in
parenthesis is the total number of repetitions performed.
Worst Residual: displays the worst residual calculated from all the
sets of the selected measurement type.
Description: is the description for the point that is being stored. This
field appears prior to storing the new point.
Note: A residual is the difference between a single measurement and
the average of all the measurements.
R-86
