Survey Pro Reference Manual
Note: Viewing the DTM during DTM Stakeout is a useful quality
assurance technique to determine where additional points are
needed.
' '70
: accesses the 3D View screen (Page R-69) where a 3D view
of the DTM can be viewed from any angle.
%DFNVLJKW
: accesses the Backsight Setup screen (Page R-78) where
the current backsight can be modified.
6ROYH
: opens the DTM Shot screen where the DTM area can be
staked.
Select Line
6WDNHRXW 6WDNH '70
The Select Line screen is used to select a particular
polyline. Separate overhead and side views are
displayed on the right side of the screen for the selected
polyline.
Simply select the desired line and tap OK.
R-152
