The Road Card
5RDGV (GLW 5RDGV
The Road card of the New Road screen is used to select the alignment
to use for the road. If an alignment has not yet been created, refer to
Page R-51 for information on creating an alignment.
Road Name: is the name assigned to the road. The name must not be
the same as any existing road name.
Alignment Description: displays the name of the selected
alignment.
&KRRVH $OLJQPHQW
where an existing alignment can be selected.
&KHFN
results in the Roads Report screen.
9LHZ 3URILOHV
can see information about the cross-sectional profile of
the road at any station.
6HW 32%«
where information about the current alignment can be
changed.
Roads Report Screen
5RDGV (GLW 5RDGV
The Roads Report screen displays a list of any errors after performing
the following tests.
•
Confirm that the alignment contains both a HAL and a VAL.
•
Confirm that the horizontal length of the VAL is greater than
or equal to the HAL.
•
Confirm there is at least one template for each side of the
road.
•
Confirm the first template coincides with the starting station.
1HZ« (GLW«
( or
: opens the Choose Alignment screen
: checks the road for errors and displays the
: opens the Road Profiles screen where you
: opens the Road Alignment Properties screen
1HZ« (GLW«
( or
Roads Menu
5RDG
)
5RDG &KHFN«
)
