Tripod Data Systems SURVEY PRO Reference Manual page 148

Survey Pro Reference Manual
Stake Spiral and Offset – Screen Two
Station to Stake: is the desired station on the spiral
curve that you want to stake.
Station Interval: is the value that is added to the Station
to Stake after the
1H[W 6WD
: advances the Station to Stake by the Station
Interval.
Offset: is the horizontal distance of the offset from the
spiral curve. The offset occurs on the left (while viewing
the spiral from the Start Point) when the
on the right when
Note: An offset of zero would result in the spiral curve
itself being staked.
9 2IIVHW
: will result in the elevations for the design points to be
adjusted by the value entered here and will change the cut / fill
values accordingly. Design elevations will be lower when is selected,
and higher when
*UDGH
: specifies a slope from the spiral curve to the curve that is
being staked. When this is a non-zero value, the elevation for the
staked points will increasingly differ from the corresponding design
elevations on the spiral curve as the Offset value increases.
Height of rod: is the length of the rod.
%DFNVLJKW«
: accesses the Backsight Setup screen (Page R-78).
%DFN
: returns to the previous screen.
6ROYH!
: accesses the third screen, described next.
Note: A motorized total station will automatically turn toward the
design point after pressing
the Stakeout Settings screen (Page R-35).
R-142
1H[W 6WD
button is pressed.
R is selected.
U is selected.
6ROYH!
depending on the configuration of
L is selected or
