Tripod Data Systems SURVEY PRO Reference Manual page 107

Resection – Screen Two
Resect Point: is the known point that you will shoot.
Option: allows you to select the type of data that is
recorded when shooting the specified foresight. You can
select Distance and Angle, or if shooting at least three
foresights, you can also select to record the Angle Only.
HR: is the length of the rod.
7DNH 6KRW« : takes a shot to the prism at the specified
foresight point. After the last shot is performed, the Save
Point dialog box will open, described next.
Save Point Screen
Once the final shot is completed, the Save Point dialog box will open
showing the computed coordinates for the occupy point.
Description: is the desired description for the point that
will be stored.
OK: stores the new point and automatically sets the
point as the current occupy point.
&DQFHO : exits the dialog without storing a new point.
Survey Menu
R-101
