Survey Pro Reference Manual
Edit Alignment Screen – POB Tab
The POB (Point Of Beginning) tab in the Edit Alignment
screen is used to define the starting location of the
alignment. The first horizontal and vertical segment
will always begin at this location.
/RFDWLRQ : the starting location for the horizontal and
vertical alignments will be at the specified North, East
and Elev coordinates.
3RLQW : the starting location for the horizontal and
vertical alignments will be at the specified Point.
Start Station: is the station on the alignment that
corresponds with the starting location or point.
Edit Alignment Screen – General Tab
The General tab in the Edit Alignment screen is used to
describe the alignment and select the layer where it is
located.
Description: is the description of the alignment.
Layer: is the layer where the alignment will be located.
$WWULEXWHV : accesses the Point Feature Attributes screen
(Page R-46) where the feature attributes for the
alignment can be selected.
R-54
