Define a Location

6WDNHRXW 'HILQH D
The Define a Location screen is used to manually enter the distance
and direction to a new point from any existing reference point and
then stakeout the new point.
From Point: is the reference point that the specified
angle and distance information is applied to for locating
the new point.
$]LPXWK
point to the new point.
+/- Angle: is the angle to be added to the specified
azimuth or bearing, thus modifying the direction to the
new point.
Note: To subtract an angle from the specified azimuth or
bearing, enter a negative +/- Angle value.
Horiz. Dist: is the horizontal distance from the reference
point to the new point.
Vert. Dist: is the vertical distance from the reference point to the new
point.
Store point: When this is checked, the computed point will be stored
with the name specified here.
6ROYH
: will compute the location for the new point and access the
next screen.
/RFDWLRQ
%HDULQJ
/ : is the direction from the reference
Stakeout Menu
R-155
