Tripod Data Systems SURVEY PRO Reference Manual page 24

Survey Pro Reference Manual
Export Old *.JOB Coordinates
This option functions exactly as the Export *.JOB routine, only the
resulting file is written to be compatible with the Survey Pro Version
2.x format, and earlier.
Export *.CR5 Coordinates
The Export CR5 dialog box will open when exporting
coordinates to a TDS CR5 coordinate file.
CR5 File Options: specifies if the resulting file should be
Sequential or Non-Sequential. (The HP 48 data collector
can only use sequential coordinate files.)
%DFN : returns to the previous screen.
([SRUW : exports the selected coordinates to the new CR5
file.
Export *.TXT Coordinates
Since the coordinates in an ASCII *.TXT file can be
stored in a variety of formats, two screens are used to
define the format of the resulting file.
Delimiters: is the character that separates each column
of text in the ASCII file.
Coordinates: is used to select if the resulting coordinates
should be plane coordinates, geodetic coordinates in
degrees-minutes-seconds format, or geodetic coordinates
in decimal format.
Units: are the distance units that will be written to the
resulting TXT file. These units are automatically set to
the same units that are set for the current job.
;
Headers in the first row: When checked, a heading
R-18
