Tripod Data Systems SURVEY PRO Reference Manual page 138

Survey Pro Reference Manual
Slope Staking – Screen Five
The fifth screen is used to store a point for the last shot taken from
the previous screen, which should be located at the catch point.
Point Name: is the name assigned to the stored point.
Description: is the description assigned to the stored
point.
6WRUH &3
: stores the point.
Offset from CP: This field is used if you want to stake
another location that is at the specified horizontal
distance from the catch point away from the road.
6ROYH !
: opens a new screen, described next, used to
stake the point at the offset specified above.
%DFN
: returns to the previous screen.
1H[W &3 !
: returns to the third slope staking screen
where the station to stake can be advanced and the next
catch point can be located.
R-132
