Panel key operation instructions:
1. Changing Wireless Channel: Press the "CHANNEL" key on the
front panel of TX to cycle through multiple 5GHz wireless channels.
If the product works unsteadily or the picture is intermittent, please
try a different channel.
2. Restore Factory Setting: Press and hold the RESET button for
three seconds. The HDMI Status LED will flash three times and the
device will restart. The OSD will show that Restore Factory Set is
successful.
The Factory Reset Button is located at the bottom of the RESET hole
found on the transmitter and receiver. Perform factory reset while the
device is powered on. User will need to use a long and slim stick like a
paper clip to press the RESET button.
Note: You must reset transmitter and all receivers before they can be used again.
Web settings:
To prevent interference caused by a device using the same frequency, the
Wireless HDMI Extender supports the set-up and adjustment of the
operating channel and SSID via the WEB. For safety, the user should
change the SSID and the password during the first login. Please follow
the below steps:
1. Connect 12V power supplies to the transmitter and all receivers, and
let them finish the pairing sequence.
2. Enable WiFi on the mobile phone / PC, search for and connect to
SSID: JTD_HDMI_Wireless_1 Enter the default password: 00000000.
3. Modify the IP address type of the mobile phone / PC to Auto (DHCP).
When you select static type, you must be
set the IP in 192.168.1. xxx address
segment range, e.g. 192.168.1.100.
4. Open the browser and scan the QR
code or enter "192.168.1.10" in the
address bar to enterthe web GUI
as shown below:
