QUICK START PROCEDURE
Connecting a PC to DC2836A
You can use a PC to reconfigure the power manage-
ment features of the LT7182S such as: nominal V

USB CABLE

USB to
I2C/PMBus Dongle
DC1613A
INPUT OR OUTPUT CAPACITOR
Figure 4. Measuring Input or Output Ripple
,
OUT
Power Supply
12-PIN (J8)
CONNECTOR
Figure 5. Demo Setup with PC
DEMO MANUAL DC2836A
margin set points, OV/UV limits, temperature fault limits,
sequencing parameters, the fault log, fault responses,
GPIOs and other functionalities. The DC1613A dongle
may be plugged when V
IN
Input
VIN
LT7182S
Demo Board
DC2836A
is present.
V
OUT0
LOAD0
V
OUT1
LOAD1
dc2836a F05
Rev. 0
5
