Page 1
M8x80 Small Hex Wrench Spring Washer Flat Washer Head Cap Bolt (long) 1 pc. 11 pcs. (+1 extra) 11 pcs. (+1 extra) 4 pcs. (+1 extra) Tool(s) required for assembly: Phillips screwdriver Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
Page 2
Assembly Instructions 2/3 IMPORTANT Use a soft cloth between these parts and the floor. Do not use power tools above 8 volts to assemble. Do not tighten all the bolts until each part is properly assembled. Keep Hex Wrench as the bolts may need to be tightened in the future.
Page 3
Assembly Instructions 3/3 Head Cap Bolt (long) Wood Screw Spring Washer Flat Washer Head Cap Bolt (short) Spring Washer Flat Washer STEP 2 Attach Back Frame (D) to unit with Flat Washers, Spring Washers, Head Cap Bolt (short), Head Cap Bolts (long), tightening bolts only halfway. (See Figures 3 and 4) Tighten all Head Cap Bolts used in Steps 1 and 2.
Page 4
Buff with a dry clean cloth. Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized retail affiliate, Home Styles is under no obligation to provide replacement parts.
