Section 4: Maintenance

Emissions Information

For warranty information, please refer to the diesel
engine manual supplied with this unit.

Daily Walk-Around Inspection

CAUTION
Equipment Damage. Failure to perform a daily
inspection could result in damage to the unit.
Perform a walk-around inspection of the unit every day
before starting the unit. Look for conditions that could
hinder performance or safety, such as (but not limited to):
Oil, coolant, and fuel leakage
Blocked vents
Loose or missing hardware
Loose or broken electrical connections
Inspect the fan belt for cracks, fraying, or stretching. Ver-
ify the belt is correctly seated in the pulley grooves.
Replace the belt according to the manufacturer's recom-
mendations.

General Maintenance

Poorly maintained equipment can become a safety
hazard. In order for the equipment to operate safely and
correctly over a long period of time, periodic maintenance
and occasional repairs are necessary. DO NOT perform
routine service (oil and filter changes, cleaning, etc.)
unless all electrical components are shut off.
Regular maintenance will improve performance and
extend engine/equipment life. Generac Mobile Products,
LLC recommends that all maintenance work be per-
formed by a GMP ASD. Regular maintenance, replace-
ment or repair of the emissions control devices and
systems may be performed by any repair shop or person
of the owner's choosing. However, to obtain emissions
control warranty service free of charge, the work must be
performed by a GMP ASD or authorized Mitsubishi
engine dealer depending on the repair. See the emis-
sions warranty.

Preparing for Service

Before servicing the unit, always follow the instructions
listed below.
1. If unit is equipped with the Power Zone™-DLA
controller, verify the main circuit breaker is OFF.
Otherwise, verify the key switch is OFF.
2. Verify the circuit breakers are switched OFF (O).
Owner's Manual for MLT6SM/6SK Light Tower
3. Disconnect the negative (–) terminal on the battery.
4. Attach a "Do Not Start" sign to the control panel to
signify that the unit is being serviced and reduce
the chance of unauthorized use.

Cleaning the Unit

Equipment damage. Never spray water to clean unit.
Do not introduce water into generator widings,
terminals, or fuel system during the cleaning process.
Doing so will result in equipment damage.
(000306)
Always clean the unit after each use to remove dust,
grease, mud, or spilled fuel or oil. Use soft, clean rags to
wipe the cabinet exterior and control panel. Low-pressure
compressed air (less than 40 psi [276 kPa]) can also be
used to remove dust and debris from the cabinet interior.
This unit contains sensitive electronic components that
can be damaged by high pressure and heat. Do not:
wash the unit with a high pressure hose or power
washer.
wash the engine block or fuel tank with a power
washer or steam cleaner. Water may enter the
cabinet and collect in the generator windings or
other electrical parts, causing damage.

Inspecting the Unit

If the unit is stored outside, inspect for water inside
the cabinet and generator before each use. If wet,
dry the unit thoroughly before starting.
Inspect condition of electrical cords. DO NOT use
the unit if insulation is cut or worn through.
Verify winch cables are in good condition and
centered on each pulley. DO NOT use a cable that
is kinked or starting to unravel.
Verify the wheel lugs are present and correctly
tightened. Refer to
Check the coolant level daily by inspecting the
level in coolant overflow jug located near the radia-
®
tor. Refer to the engine operator's manual for cool-
ant recommendations and proper mixture. Normal
operating level is between the 'full' and 'add' mark-
ings on the overflow jug.
After engine is stopped and completely cool, cool-
ant may be added directly to the coolant overflow
jug.
Check the oil level daily. Refer to the engine opera-
tor's manual for the appropriate oil specification.
Maintenance
CAUTION
(000325a)
Towing
Safety.
39
