Swivel Chair
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

A.
Seat
1 pc.
E.
Leg
2 pcs.
F.
Leg
2 pcs.

Hardware List

Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
B.
Arm
1 pc.
G.
Side Stretcher
2 pcs.
H.
Side Stretcher
2 pcs.
M x4
4 5
Wood Screw
8 pcs.(+1 extra)
M6x
20
M6x40
Head Cap Bolt
Head Cap Bolt
(20mm)
(40mm)
4 pcs.(+1 extra)
7 pcs.(+1 extra)
C.
Arm
1 pc.
D.
Back Frame
1 pc
.
I.
Base
1 pc.
Flat Washer
13 pcs.(+1 extra)
M6x50
Head Cap Bolt
(50mm)
4pcs.(+1 extra)
Spring Washer
9 pcs.(+1 extra)
M6x
85
Head Cap Bolt
(85mm)
4 pcs.(+1 extra)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 88 5601 81 and is the answer not in the manual?

Questions and answers

Summary of Contents for Home Styles 88 5601 81

  • Page 1 88 5 601 1 Swivel Chair IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed.
  • Page 2 Assembly Instructions 2/4 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. STEP 1 Attach Stretchers (G) to Legs (E) and (F).
  • Page 3 Assembly Instructions 3/4 Wood Screw STEP 3 Turn the base unit upside down. Insert Wood Screws and tighten. (see Figure 2) Figure 2 Head Cap Bolt (85mm) Spring Washer Flat Washer Figure 4 Figure 3 Head Cap Bolt (40mm) Spring Washer Flat Washer STEP 4 Turn Seat (A) upside down.
  • Page 4 Assembly Instructions 4/4 Figure 5 STEP 5 Rotate the swivel plate. (see Figure 5) Head Cap Bolt (20mm) Flat Washer Figure 6 STEP 6 Place the base unit onto the top unit and attach it with Flat Washers and Head Cap Bolts (20mm).
