Summary of Contents for Southern Enterprises HZ102800TX
- Page 1 HZ102800TX Dowd Cabinet For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Dowd Cabinet Assembly Instructions Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 2 of 2 of 2 Drawer Right Panel Drawer Left Panel Drawer Right Panel Quantity Quantity Quantity of 2 of 1 of 4 Drawer Bottom Panel Back Panel Quantity Quantity Quantity of 22 of 22 of 18 Cam Lock Wood Dowel Ø...
- Page 4 Quantity Quantity Quantity of 21 of 4 of 2 Handle Magnet Screw ∅1/8"x1" Quantity Quantity Quantity of 2 of 4 of 4 Screw Screw ∅1/8"x5/8" Ø 1/8” x 1-5/8”L Magnet Plate Quantity Quantity Quantity of 4 of 4 of 2 Anchor Plastic Strap Bracket...
- Page 5 Dowd Cabinet Assembly Instructions Please separate Drawer Slides (20) into male and female components as shown. Note: There is a lever located on the male slide. Push the lever to the either side while pulling in order to detach the male slide from the female slide.
- Page 6 Attach Female Drawer Slide (20) to Right Side Panel (D) using Flat Head Screws (4). Tighten Flat Head Screws (4) with Phillips screwdriver. Figure 3 Attach two Female Drawer Slides (20) to Middle Vertical Panel (G) using Flat Head Screws (4). Tighten Flat Head Screws (4) with Phillips screwdriver.
- Page 7 Screw with fingers to help align cam bolts before using screwdriver. Insert Cam Locks (2) into corresponding holes on Middle Vertical Panel (G). Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Lower Fixed Shelf Panel (E) and Upper Fixed Shelf Panel (F).
- Page 8 Insert Cam Locks (2) into corresponding holes on assembled unit from Figure 5 Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Left Side Panel (C) and Right Side Panel (D). Attach Left Side Panel (C), Right Side Panel (D) and Front Crosspiece (H) to assembled unit from Figure 6 by inserting Wood Dowels (3) and Cam...
- Page 9 Insert Cam Locks (2) into corresponding holes on assembled unit from Figure 7. Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Top Panel (A) and Bottom Panel (B). Attach Top Panel (A) and Bottom Panel (B) to assembled unit from Figure 7 by inserting Wood Dowels (3) and Cam Bolts (1) into corresponding holes until...
- Page 10 Attach the Metal Plate (13) on the inner inside of the Left Door (J) using Flat Head Screws (4) Attach the Hinges (7) to the Door (I) using Flat Head Screws (4) Tighten Flat Head Screws (4) with Phillips screwdriver. Attach the Door Handle (11) on the door using Bolt for Handle (5).
- Page 11 Attach Doors (J/K) to the unit using Flat Head Screws (4). Tighten Flat Head Screws (4) with Phillips screwdriver. Cover Cam Locks with Cover (19) as shown. Figure 13 Attach Male Drawer Slide (20) to Drawer Side Panels (M/N) using Flat Head Screws (4).
- Page 12 Attach Drawer Back Panel (O) to Drawer Side Panels (M/N) using Screws (10). Tighten Screws (10) with Phillips screwdriver. Insert Drawer Bottom Panel (P) into the grooves of assembled unit. Figure 15 Attach Drawer Front Panel (L) to assembled unit using Screws (10). Tighten Screws (10) with Phillips screwdriver.
- Page 13 Insert drawers into assembled unit. Make sure drawer’s male ball bearing slides are carefully inserted into side panel’s female ball bearing slide. Make sure ball bearing slides glide smoothly in and out. Figure 17 Attach Brackets (16) to back panel using Screws (14).
- Page 14 Move this item close to the wall Brackets (16) and tie in all Brackets (16) together with Plastic Straps (18) as shown in diagram. Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 19 Tip: If the Cabinet is not level, please adjust the Leg’s leveler by hand as shown.
-
Page 15: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas) Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
