Southern Enterprises HZ1032A0TX Assembly Instructions Manual

Shadowbox wine/bar cabinet
Hide thumbs

Advertisement

Quick Links

Download this manual
HZ1032A0TX/ HZ1032B0TX
Shadowbox Wine/Bar
Cabinet
Assembly Instructions
Following detailed instructions, assembly should take approximately two hours.
Due to weight, assembly requires two people.
For assistance with assembly contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
www.seidal.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HZ1032A0TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Southern Enterprises HZ1032A0TX

Summary of Contents for Southern Enterprises HZ1032A0TX

  • Page 1 HZ1032A0TX/ HZ1032B0TX Shadowbox Wine/Bar For assistance with assembly contact: Cabinet Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com Due to weight, assembly requires two people. Following detailed instructions, assembly should take approximately two hours.
