- Page 1 HZ104300TX Redding Bar Cabinet For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Redding Bar Cabinet Assembly Instructions Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 4 of 1 of 1 Upper Door Handle Mirror Quantity of 2 Lower Door Handle Quantity Quantity Quantity of 16 of 16 of 20 Cam Lock Wood Dowel Ø 8 x 30mm Cam Bolt Quantity Quantity Quantity of 2 of 30...
- Page 4 Quantity Quantity Quantity of 4 of 4 of 2 Round Head Bolt T- Nut Bolt For Semicircle Hinges Quantity Quantity Quantity of 16 of 16 of 16 Flat Washer Ø1/4” Spring Washer Ø1/4” Bolt for Leg Ø1/4”x5/8”L Quantity Quantity Quantity of 1 of 1 of 10...
- Page 5 Redding Bar Cabinet Assembly Instructions Screw with fingers to help align screws before using screwdriver. Attach Magnets (4) to Top Panel (A) using Flat Head Screws (5). Tighten Flat Head Screws (5) with Phillips screwdriver. Figure 1 Screw with fingers to help align cam bolts before using screwdriver.
- Page 6 Insert Cam Locks (2) into corresponding holes on Upper Middle Panel (E). Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Fixed Shelf Panel (G). Attach Upper Fixed Shelf Panel (G) to assembled unit by inserting Wood Dowels (3) and Cam Bolts (1) into corresponding holes until Upper Fixed Shelf Panel (G) and the assembled unit...
- Page 7 Insert Cam Locks (2) into corresponding holes on assembled unit from Figure 4. Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Left Side Panel (C). Attach Left Side Panel (C) to the assembled unit from Figure 4 by inserting Wood Dowels (3) and Cam Bolts (1) into corresponding holes until Left Side Panel (C) and the assembled...
- Page 8 Insert T-Nuts (11) into corresponding holes on the bottom of Side Panels (C/D). Attach Bottom Panel (B) to the assembled unit from Figure 6 by inserting Wood Dowels (3) into corresponding holes until panels meet. Insert Bolts (10) though corresponding holes on bottom of Bottom Panel (B) and into T-nuts (11).
- Page 9 Attach Back Panel (L) to backside of the assembled unit from Figure 8 with Round Head Screws (5). Tighten Screws (5) with a Phillips screwdriver. Note: Make sure the arrow on the rear of the Back Panel (L) is pointing up. Figure 9 Attach Legs (M) to Bottom Panel (B) with Bolts (13), Spring Washers (15) and...
- Page 10 Attach Hinges (8) to Door Panels (I) and (J) with Screws (9) as shown. Tighten Screws (9) with Phillips screwdriver. Figure 11 Attach Door Panels (I/J) to the assembled unit from Figure 10 with Screws (9) as shown. Tighten Screws (9) with Phillips screwdriver.
- Page 11 Attach Lower Door Handle (P) to Door Panels (I/J) with Screws (6). Tighten Screws (6) with Phillips screwdriver. Figure 13 Insert Shelf Pins (7) into corresponding holes on the Side Panels. Place Adjustable Shelf (H) onto Shelf Pins as show. Figure 14 Page | 11...
- Page 12 Attach Upper Door Handle (O) to Upper Turnover Door (K) with Screws (6). Tighten Screws (6) with Phillips screwdriver. Figure 15 Insert Upper Turnover Door (K) into corresponding holes on Upper Fixed Shelf Panel as shown. Connect Upper Turnover Door (K) to the assembled unit from Figure 15 with Bolts (12).
- Page 13 Attach Supports (16/17) to the assembled unit with Screws (18) as shown. Tighten Screws (18) with Phillips screwdriver. Figure 17 Attach Supports (16/17) to Upper Turnover Door (K) with Screws (18) as shown. Tighten Screws (18) with Phillips screwdriver. Figure 18 Page | 13...
- Page 14 Attach Brackets (22) to back panel using Screws (19). Tighten Screws (19) using Philips screwdriver. Mark two desired locations on wall and drill two 3/16" holes for each Bracket (22). Insert Plastic Anchors (21) into two holes for each Bracket (22) on wall as shown.
- Page 15 Tip: If the Bar Cabinet is not level, please adjust the Leg’s Leveler by hand as shown. Now your Redding bar cabinet is ready for use. Figure 21 Page | 15...
-
Page 16: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas) Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
