- Page 1 HZ104700TX Marc Bar Cabinet For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Marc Bar Cabinet Assembly Instructions Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 1 of 1 of 1 Upper Back Panel Middle Back Panel Lower Back Panel Quantity Quantity Quantity of 40 of 40 of 40 Cam Lock Wood Dowel Ø 8 x 30mm Cam Bolt Quantity Quantity Quantity of 28 of 4 of 34...
- Page 4 Quantity Quantity Quantity of 4 of 4 of 4 Screw Anchor Ø 1/8” x 1-5/8”L Screw ∅1/8"x5/8" Quantity Quantity of 2 of 24 Cover Plastic Strap Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please Periodically apply furniture wax to renew call customer service at 1-800-633-5096.
- Page 5 Marc Bar Cabinet Assembly Instructions Screw with fingers to help align cam bolts before using screwdriver. Insert Cam Locks (2) into corresponding holes on Small Fixed Shelf Panel (J). Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Left Vertical Panel (G).
- Page 6 Insert Cam Locks (2) into corresponding holes on assembled unit from Figure 1 and Figure 2. Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Upper Fixed Shelf Panel (E) and Under Fixed Shelf Panel (F) Attach Upper Fixed Shelf Panel (E) and Lower Fixed Shelf Panel (F) to assembled unit by inserting Wood...
- Page 7 Insert Cam Locks (2) into corresponding holes on assembled unit. Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Left Side Panel (C) and Right Side Panel (D) Attach Left Side Panel (C) and Right Side Panel (D) to assembled unit by inserting Wood Dowels (3) and Cam Bolts (1) into corresponding holes until Left Side Panel (C), Right Side Panel...
- Page 8 Attach Magnets (7) to Bottom Panel (B) using Round Head Screw (6) as shown. Tighten Round Head Screw (6) with Phillips screwdriver. Figure 7 Insert Cam Locks (2) into corresponding holes on the top and bottom of the assembled unit. Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Top Panel (A) and Bottom Panel (B)
- Page 9 Attach Back Panels (M/N/O) to backside of the unit with Round Head Screws (6) and Metal Plates (11). Tighten Screws (6) with a Phillips screwdriver. Figure 9 Attach the Metal Plate (10) to the inside of the Left Door (K) using Flat Head Screws (4).
- Page 10 Attach the Metal Plate (10) to the inside of the Right Door (L) using Flat Head Screws (4). Attach the Hinges (9) on the Right Door (L) using Flat Head Screws (4). Tighten Flat Head Screws (4) with Phillips screwdriver. Attach Handle (8) to the door using Bolts for Handle (5).
- Page 11 Attach Brackets (12) to back panel using Screws (13). Tighten Screws (13) using Philips screwdriver. Mark two desired locations on wall in the same distance as the brackets on the back of the unit and drill two 3/16" holes for each Bracket (12). Insert Plastic Anchors (15) into the holes for each Bracket (12) on wall as shown.
- Page 12 Now your Marc Bar Cabinet is ready for use. Figure 20 Page | 12...
-
Page 13: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas) Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
