- Page 1 HZ636300TX Maydell 3-Drawer Storage For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO:13778 Support loading capacities Top: max 25 lbs...
- Page 2 HZ636300TX Maydell 3-Drawer Storage Parts List Please review all parts and hardware before disposing of any packaging. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage. Top board Right side Left side board...
- Page 3 HZ636300TX Maydell 3-Drawer Storage Assembly Instructions Step 1 Assembly should begin with parts turned upside down for Step 1. Use Short Screw (5) to attach Slide Track (I) on Right Board (B) and Left Side Board (C). Figure 1...
- Page 4 Step 2 Screw Cam Bolts (1) into the threaded holes and insert Wood Dowels (4) into the hollow holes on Top Board (A). Attach Right/Left Side Boards (B/C) onto Top Board (A) by inserting Wood Dowels and Cam Bolts into their corresponding holes until all panels meet.
- Page 5 Step 4 Attach Legs (F) onto the bottom board and turn clockwise by hand to tighten. Turn the assembled unit upright. Figure 4 Step5 Attach Wood Handle (H) onto the drawer and use the supplied screws to secure. Insert the drawer bottom (E) into the drawer.
- Page 6 Step6 Insert the drawers inside the shelf. Now your unit is complete. Figure6 Customer Service 1-800-633-5096 service@seidal.com Southern Enterprises, Inc. 600 Freeport Parkway, Suite 200 Coppell, Texas 75019...
- Page 7 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
