Southern Enterprises HZ106300TX Assembly Instructions Manual

Hagan storage cabinet
Hide thumbs

Advertisement

Quick Links

Download this manual
HZ106300TX
Hagan Storage Cabinet
For assistance with assembly, contact.
Southern Enterprises Inc.
Customer Service 1-800-633-5096
Assembly Instructions
service@seidal.com
www.seidal.com
PO:13411
Top supports up to 40 lb.
Per adjustable shelf supports up to 20 lb.
Fixed bottom shelf supports up to 30 lb.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HZ106300TX and is the answer not in the manual?

Questions and answers

Related Manuals for Southern Enterprises HZ106300TX

Summary of Contents for Southern Enterprises HZ106300TX

  • Page 1 HZ106300TX Hagan Storage Cabinet For assistance with assembly, contact. Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO:13411 Top supports up to 40 lb. Per adjustable shelf supports up to 20 lb. Fixed bottom shelf supports up to 30 lb.

  • Page 2: Parts List

    HZ106300TX HAGAN STORAGE CABINET Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. Top Panel Left Panel...
  • Page 3 4PCS 8PCS 6PCS Magnet Screw 3x15mm Wood Dowel Cam Bolt 6PCS 10PCS 4PCS Cam Lock Screw 8x1-1/2”L Bolt 3/16”x1/2”L End Cap 2PCS 2PCS 4PCS 16PCS Iron Chip Screw 3x8mm Door Hinge Screw 6x1/2”L 8PCS 4PCS 2PCS 2PCS Bracket L Metal Chip Screw 4x12mm Wall Anchor...
  • Page 4 HZ106300TX HAGAN STORAGE CABINET Assembly Instructions Step 1 Unit assembly should begin with parts turned upside down for Step 1. Attach magnet (A) into the pre-drilled holes on Top Panel (1) using Screws (B) as shown. Attach Left Panel (2) and...
  • Page 5 Step 3: Slide Back Panel (4) along the grooves of Left Panel (2) and Right Panel (3). Then, attach Wood Dowels (C) to Left Panel (2) and Right Panel (3) as shown. Figure 3 Step 4: Attach Bottom Panel (5) to the assembled unit using Screws (F) as shown.
  • Page 6 Step 5: Attach Lower Leg (10) to Upper Leg (9) using Bolt (G). Then, aim at the pre-drilled holes on the Bottom Panel (5) to attach the assembled Leg Frame to Bottom Panel (5) using Screws (F) as shown. Attach End Caps (H) to Legs (9) and (10) as shown.
  • Page 7 Step 7: Turn the assembled unit upright. Attach Doors (7) and (8) w/Door Hinges (K) to the grooves of Left Panel (2) and Right Panel (3) using Screws (L) as shown. Figure 7 Step 8: Insert Brackets (M) into the holes on the insides of Left Panel (2) and Right Panel (3) and make sure the positions...
  • Page 8 Anti-tipping Hardware Must be Used for this product to avoid tipping and injury Aim at the pre-drilled holes on the back of Left Panel (2) and Right Panel (3) to attach L Metal Chip (N) using Screws (O) as shown. Tip: Screw must be directly mounted into a wall stud.
  • Page 9 Attach L Metal Chip (N) to Wall Anchor (P) u sing Phillips Head Screws (Q) and the Phillips Screwdriver as shown. Attach Plastic Strap (R) to L Metal Chip (N) on the wall and cabinet as shown.

  • Page 10: Parts Replacement Form

    90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
