- Page 1 HZ105100TX Halifax Double-Door Cabinet For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 3 HZ105100TX Halifax Double-Door Cabinet For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PARTS LIST: DESCRIPTION DESCRIPTION Top Panel Bottom Panel Left Side Panel Right Side Panel Left Glass Door Right Glass Door Back Panel Fixed Shelf...
- Page 4 Assemble the legs (J) and bottom panel (B) using allen wrench (1), allen wrench screws (2), and hardware (3) (4) as shown in figure 1. Figure 1 Step 1Customer Service 1-800-633-5096 service@seidal.com Southern Enterprises, Inc. 600 Freeport Pkwy Ste: 200 Coppell, Texas 75019...
- Page 5 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions Step 1: Tighten the magnets (11) on the top panel (A) and bottom panel (B) using screws (6) as shown in figure2. Figure 2...
- Page 6 HZ105100TX Halifax Double-Door Cabinet STEP 3 Assembly Instructions Step 1: Assemble the left side panel (C), right side panel (D), and fixed shelf (H) using wood d o we ls (5 ) a s s h o wn in figure 3.
- Page 7 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions STEP 3 Step 1: Join the top panel (A) and b o t to m pa ne l (B ) to th e assembly from figure3 using wood dowels (5) as shown in figure 4.
- Page 8 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions Step 1: STEP 5 Tighten the back panel (G) to the assembly using round head screws (7) as shown in figure 5. Figure 5...
- Page 9 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions Step 1: Insert the pins (10) at the desired position and place the adjustable shelf (I) above the pins as shown in figure 6. Figure 6...
- Page 10 STEP 7 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions Step 1: Assemble the door panels (E) and (F) to the assembly as shown in figure 7. Step 2: Tighten the door handles (9) to the door panels (E) and (F) using screws (8) through the pre-drilled holes as shown in figure 7.
- Page 11 HZ105100TX Halifax Double-Door Cabinet Assembly Instructions T O A V O I D I T E M T I L T I N G F OR WA R D. MO U NTI N G T O THE WALL IS REQUIRED.
-
Page 12: Parts Replacement Form
If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon- Fri Central time if you have product issues or email us at service@ hollyandmartin.com...
