HZ104100TX
Black Contemporary Bar
Cabinet
For assistance with assembly contact:
Southern Enterprises, Inc.
ASSEMBLY INSTRUCTION
Customer Service 1-800-633-5096
service@seidal.com
www.seidal.com
PO#:
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HZ104100TX and is the answer not in the manual?

Questions and answers

Summary of Contents for Southern Enterprises HZ104100TX

  • Page 1 HZ104100TX Black Contemporary Bar Cabinet For assistance with assembly contact: Southern Enterprises, Inc. ASSEMBLY INSTRUCTION Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page 1...
  • Page 2: Parts List

    Black Contemporary Bar Cabinet Parts list Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the diagrams below.
  • Page 3 Quantity Quantity Quantity of 1 of 4 of 2 Drawer bottom Middle glass rack Side Glass rack Quantity Quantity Quantity of 4 of 4 of 32 Wood Dowel Metal rack Dia5/16”x1-3/16”L Legs Quantity Quantity Quantity of 32 of 32 of 6 cam bolt Cam lock hinge...
  • Page 4 Quantity Quantity Quantity of 4 of 18 of 4 Metal bracket screw :Dia1/8”x1-1/4”L screw :Dia1/8”x1”L Quantity Quantity Quantity of 4 of 2 of 2 screw :Dia1/8”x5/8”L bracket Plastic chain Quantity Quantity of 2 of 4 anchor screw :Dia1/8”x1-3/8”L Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
  • Page 5 Black Contemporary Bar Cabinet Assembly Instructions Assembly Instructions: Wood may scratch easily, Be careful when assembling. Do not scratch. Attach female slide left (10) to left side panel(C) with screw (5). Tighten screws with a phillips screwdriver (not included) Figure 1 Attach female slide right (12) to right side panel (D) with screw (5),...
  • Page 6 Insert cam lock (3) into predrilled holes on fixed shelf panel (E) Screw cam bolt (2) into pre-drilled holes on left side panel (C). Attach left side panel (C) to fixed shelf panel (E) by inserting wood dowel (1) & cam bolt (2) into corresponding pre-drilled holes until left side panel (C) &...
  • Page 7 Attach leg (S) to pre-assembled unit on figure 5 by hand. Attach middle glass rack (Q) & side glass rack (R) to pre-assembled unit on figure 5 with screw (15). Tighten with a Phillips screwdriver. Figure 6 Attach wine rack vertical panel (H) &...
  • Page 8 Attach back panel (F) to back side of pre-assembled unit on figure 8 with screw (6). Tighten screws with a Phillips screwdriver. Figure 9 Attach metal rack (T) to left door (I) & right door (J) with screw (5). Attach knob (7) to left door (I) & right door (J) with small bolt (8).
  • Page 9 Attach metal bracket (14) to pre-assembled unit on figure 11 with screw 5. Tighten screw with a phillips screwdriver. Figure 12 Attach hinge (4) to the inside pre-assembled on figure 12 & figure 9 with screw (5). Tighten screws with a Phillips screwdriver.
  • Page 10 Attach the drawer side panel left (M) & drawer side panel right (N) to drawer back panel (O) and line up the groove. Secure them with screw (16). Insert drawer bottom panel (P) into the corresponding groove of drawer back panel (O) & drawer side panel left (M) &...
  • Page 11 Insert drawer box into the unit. Please check to make sure drawer box side’s male slides are inserted into side panel’s female slide. Figure 16 Page 10 Attach Bracket (18) to back Panel using Screw (17). w all Tighten screw (17) using a Philips screwdriver.
  • Page 12 Figure 18 Your Black Contemporary Bar Cabinet is ready for use Figure 19 Page 11...
  • Page 13: Parts Replacement Form

    90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
