Summary of Contents for Philco PXI 3652 X
- Page 1 SIDE-BY-SIDE REFRIGERATOR OWNER’S MANUAL PXI 3652 X PXI 3652 NFDX...
- Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user’s manual. Copyright © 2015, Fast ČR, a. s. Revision 05/2015...
-
Page 3: Table Of Contents
CONTENTS 1. SAFETY PRECAUTION ..........................7 2. PARTS ................................8 3. PLACEMENT ..............................9 4. OPERATION CHECK ............................10 5. CONTROL PANEL ............................11 OPERATION DESCRIPTION ................................11 FRIDGE TEMPERATURE SETTING ...............................11 FREEZER TEMPERATURE SETTING ............................11 6. MODE DESCRIPTION ..........................12 MODE SETTING ....................................12 SMART MODE....................................12 QUICK COOLING MODE ................................12 QUICK FREEZE MODE ..................................12 HOLIDAY MODE ....................................12 FRAPPE MODE ....................................12... - Page 4 WARNINGS • THE APPLIANCE HAS TO BE UNPLUGGED AFTER USE AND BEFORE CARRYING OUT USER MAINTENANCE ON THE APPLIANCE. • THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS(INCLUDING CHILDREN) WITH REDUCED PHYSICAL,SENSORY OR MENTAL CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY. • CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE.
- Page 5 • PLEASE ABANDON THE REFRIGERATOR ACCORDING TO LOCAL REGULATORS FOR IT USE FLAMMABLE BLOWING GAS. • KEEP VENTILATION OPENINGS, IN THE APPLIANCE ENCLOSURE OR IN THE BUILT-IN STRUCTURE, CLEAR OF OBSTRUCTION. • DO NOT STORE EXPLOSIVE SUBSTANCES SUCH AS AEROSOL CANS WITH A FLAMMABLE PROPELLANT IN THIS APPLIANCE. • THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLD AND SIMILAR APPLICATIONS SUCH AS - STAFF KITCHEN AREAS IN SHOPS, OFFICES AND OTHER WORKING ENVIRONMENTS;...
- Page 6 • THE APPLIANCE HAS TO BE UNPLUGGED AFTER USE AND BEFORE CARRYING OUT USER MAINTENANCE ON THE APPLIANCE. • WARNING: KEEP VENTILATION OPEN, IN THE APPLIANCE ENCLOSURE OR IN THE BUILT-IN STRUCTURE, CLEAR OF OBSTRUCTION. • WARNING: DO NOT USE MECHANICAL DEVICES OR OTHER MEANS TO ACCELERATE THE DEFROSTING PROCESS, OTHER THAN THOSE RECOMMENDED BY THE MANUFACTURER.
- Page 7 • THE REFRIGERATOR MUST BE DISCONNECTED FROM THE SOURCE OF ELECTRICAL SUPPLY BEFORE ATTEMPTING THE INSTALLATION OF ACCESSORY. • REFRIGERANT AND CYCLOPENTANE FOAMING MATERIAL USED FOR REFRIGERATOR ARE FLAMMABLE. THEREFORE, WHEN THE REFRIGERATOR IS SCRAPPED, IT SHALL BE KEPT AWAY FROM ANY FIRE SOURCE AND BE RECOVERED BY A SPECIAL RECOVERING COMPANY WITH CORRESPONDING QUALIFICATION OTHER THAN BE DISPOSED BY COMBUSTION, SO AS TO PREVENT DAMAGE TO THE ENVIRONMENT OR ANY OTHER HARM.
- Page 8 • TO AVIOD CONTAMINATION OF FOOD , PLEASE RESPECT THE FOLLOWING INSTRUCTIONS: OPENING THE DOOR FOR LONG PERIODS CAN CAUSE A SIGNIFICANT INCREASE OF THE TEMPERATURE IN THE COMPARTMENTS OF THE APPLIANCE. - CLEAN REGULARLY SURFACES THAT CAN COME IN CONTACT WITH FOOD AND ACCESSIBLE DRAINAGE SYSTEMS. - CLEAN WATER TANKS IF THEY HAVE NOT BEEN USED FOR 48 H;...
-
Page 9: Safety Precaution
1. SAFETY PRECAUTION PLEASE ALWAYS FOLLOW THE SAFETY HINT LISTED BELOW: The power supply for the unit should be exactly the same as described on the data sheet, and use the standard tri-prong socket. The unit should be operated in the absence of flammable or explosive fumes. -
Page 10: Parts
2. PARTS Due to the production’s improvement, the unit you purchased maybe different from below sketch. Shelf Crisper Freezer Shelf Refrigerator Door Rack Bottle Rack Adjustable Feet EN - 8 Copyright © 2015, Fast ČR, a. s. Revision 05/2015... -
Page 11: Placement
3. PLACEMENT The unit should be placed in a ventilated and dry environment. Do not put the unit in direct sunshine, and keep it as far as possible from heat sources. The unit should be placed on flat and steady ground. Keep the unit level by adjusting the front leg levelers. -
Page 12: Operation Check
4. OPERATION CHECK Make sure the unit has been placed properly and all instructions have been observed. Use the appliance safely Adjust the control knob to the middle position, and then plug in the unit. After closing the door for several minutes, both side of cabinet becomes warm. -
Page 13: Control Panel
5. CONTROL PANEL Use your appliance according to the following control regulations, your appliance has the corresponding functions as the control panels showed in the pictures below. OPERATION DESCRIPTION Keep long press “unlock” button for 3 seconds, then you can press other buttons for operating. Touch the “room”... -
Page 14: Mode Description
6. MODE DESCRIPTION MODE SETTING Press the “function” button, the current mode will flash; you can choose between smart, quick cooling, quick freeze, holiday and other four modes by pressing the “function” button; If there is no operation for more than 5 S, the default will be confirmed, then the settings take effect;... -
Page 15: Food Storage
7. FOOD STORAGE The temperature in the fresh compartment is between 0 ~ 10 °C, although this lower temperature can limit the bacteria propagation, it is not suitable for a long period of food storage. FRESH FOOD STORAGE Cooked food should be cooled down to room temperature before putting into the refrigerator. It is better to put the food in a sealed bag before placing into the refrigerator. -
Page 16: Frozen Food Storage
FROZEN FOOD STORAGE The temperature of the freezer is colder than -18 °C. It is to store food to be kept for a long period. After buying frozen food, please put it into the freezer compartment as soon as possible. The best reserve temperature is below -18 °C... -
Page 17: Maintenance
8. MAINTENANCE CLEANING Always unplug the unit before cleaning. The unit should be cleaning frequently both inside and outside using water and a little neutral detergent. Never use boiling water, harsh cleaning agents, acid, alkali or benzene etc. This product must be serviced by an authorized service center, and only genuine spare parts must be used. 1) If the appliance is frost free. -
Page 18: Leaving The Nuit Switched Off
LEAVING THE NUIT SWITCHED OFF If the unit will be switched off for a long time, the plug should be pulled out, the clean the unit thoroughly. Ensure that the door cannot be fully closed (leaved a suitable gap), and place the unit in a well-ventilated area to avoid any odour. -
Page 19: Trouble Shooting
9. TROUBLE SHOOTING If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service,please see below. Warning! Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service engineer or the shop where you purchased the product. -
Page 20: Fault Display
PROBLEM POSSIBLE CAUSE & SOLUTION Check that the air outlets are not blocked by food and ensure food is placed A layer of frost occurs in within the appliance to allow sufficient ventilation. Ensure that door is fully the compartment closed. -
Page 21: Technical Data
DATA SHEET DATA SHEET: Philco Philco trademark: Brand: Philco PXI 3652 X / PXI 3652 NFDX Model identification Appliance type Energy efficiency class (A… low electricity consumption to G… high electricity consumption) Energy consumption over a 365 day period 1) (kWh) - Page 22 ENERGY SAVING TIPS • The appliance should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of the direct sunlight. • Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil. • Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts down on frost build-up inside the appliance. • Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with cold air circulation, making the appliance less efficient.
- Page 23 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
- Page 25 Manufacturer/Importer: Fast ČR, a.s. Praha 10, Černokostelecká 2111 CZ-10000; CZECH REPUBLIC is a registered trademark used under license from SK - 22 Electrolux Home Products., Inc. Copyright © 2015, Fast ČR, a. s. Revízia 05/2015...
