General features of your appliance 1. Thanks to patented trizbar design fracture risk occurring due to misuse by users, which is common for opponent manufacturers, has been eliminated. 2. Our new No-Frost technology ensures that the air circulates separately in the cooler and freezer compartments.
Index General features of your appliance ............1 BEFORE USING YOUR FRIDGE ...........4 1. General warnings .................. 4 .2 Old and out-of-order fridges ..............8 1.3 Safety Warnings .................. 8 1.4 Installing and Operating your Fridge ........... 9 1.5 Before Operating your Fridge ............. 10 1.5 General information about new NO FROST Technology ....
Page 4
PLACING THE FOOD ..............19 3.1 Cooler Compartment ................19 3.2 Deep-Freeze Compartments .............. 21 CLEANING & MAINTENANCE ............25 4.1 Replacing LED lights used for illumination ......... 25 SHIPMENT AND REPOSITIONING ..........26 BEFORE CALLING SERVICE ............27 6.1 Recommendations for Energy Saving ..........29 PRODUCT FICHE..................
PART 1. BEFORE USING YOUR FRIDGE 1. General warnings WARNING: Keep the ventilation openings of the Fridge clear from obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process. WARNING: Do not use other electrical appliances inside the Fridge.
Page 6
BEFORE USING YOUR FRIDGE • This appliance is intended to be used in household and domestic applications such as: - staff kitchen areas in shops, offices and other working environments. - farm houses and by clients in hotels, motels and other residential type environments.
Page 7
BEFORE USING YOUR FRIDGE people can use appliances safely after they have been given appropriate supervision or instruction concerning use of the appliance. Very vulnerable people are not expected to use appliances safely unless continuous supervision is given. • If the supply cord is damaged, it must be replaced by the manufacturer, an authorised service agent or similar qualified persons, in order to avoid a hazard.
Page 8
BEFORE USING YOUR FRIDGE The water dispenser is available • Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has not been drawn for 5 days. EN - 7 -...
BEFORE USING YOUR FRIDGE .2 Old and out-of-order fridges • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC.
BEFORE USING YOUR FRIDGE • When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or cuts. • Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes immediately after you have taken them out of the ice-making compartment. •...
BEFORE USING YOUR FRIDGE 1.5 Before Operating your Fridge • When using your fridge for the first time, or after transportation, keep it in an upright position for at least 3 hours before plugging into the mains. This allows efficient operation and prevents damage to the compressor. •...
PART 2. USE OF APPLIANCE 2.1 Introducing parts The purpose of this presentation is informing you about the parts of your appliance. The parts may vary depending on the model of the appliance. A) Cooler Compartment 7) Eggcups B) Fridge / Freezer Compartment 8) Door bottle shelves B1.
USE OF APPLIANCE 2.2 Electronic display and usage 1. Fridge Compartment Temperature indicator 11. Child lock 2. Left Freezer Compartment Temperature indicator 12. Dealer-Demo mode 3. Right Freezer Compartment Temperature indicator 13. Low voltage warning 4. Super cooling light 14. Alarm 5.
USE OF APPLIANCE 2.2.1 Beverage cooling (QDRINK) Press the [q.drink] button to activate beverage cooling mode. Each press will increment the time in segments of 5 minutes up to a maximum of 30 minutes, after which it will return to zero.
USE OF APPLIANCE 2.2.7 Freezer / Cooler 1 [ZONE 1] This is the temperature setting button for the bottom-left compartment. By pressing the [zone 1] button the temperature of the bottom-left compartment can be set to -16, -17, -18, -19, -20, -21, -22, -23 or -24 °C.
USE OF APPLIANCE 2.2.15 Using a Freezer Compartment as Cooler Compartment Based On Demand The bottom left compartment on the appliance can be used either as freezer or as a cooler. Press and hold the [zone 1] button for 3 seconds to change the bottom-left compartment from a freezer to a cooler.
USE OF APPLIANCE 2.4 Accessories 2.4.1 Icebox • Remove the icebox by grasping its front side and pulling towards you. • Fill ¾ of icebox with water and reinsert the icebox. • You can take ice after approximately 2 hours. You can service the icebox by extracting it. Icebox Note: When replacing the icebox after filling it with water, make sure that you position it horizontally without tilting it.
USE OF APPLIANCE 2.4.3 Vegetable Bowl and Chiller (Breakfast) Chiller / Breakfast Crisper Chiller / Breakfast When this compartment is used as chiller compartment, it ensures that your food is preserved at 0°C. You can place frozen food in this compartment to defrost. You can also keep meat and/or cleaned fish (in plastic bags or packets) which you plan to use within 1-2 days.
USE OF APPLIANCE 2.4.4 CRISPER AIR SETTING BUTTON Turn the air adjustment knob between crisper and chiller to the open position when the crisper is very full. This means that food in the crisper will remain fresh for a longer period of time.
PART 3. PLACING THE FOOD 3.1 Cooler Compartment • Under normal operating conditions, set the temperature of the cooler compartment to +4 / +6 • To avoid frosting, humidification and odour, food should be placed in the fridge in closed containers or covered with appropriate material.
Page 21
PLACING THE FOOD Where to place in the Food Maximum Storage time fridge department Vegetables and fruits 1 week Vegetable bin Wrapped in plastic foil or bags or in a meat container Meat and fish 2 - 3 Days (on the glass shelf) Fresh cheese 3 - 4 Days In special door shelf...
PLACING THE FOOD 3.2 Deep-Freeze Compartments • The freezer compartment is used for freezing fresh food, for storing frozen foods for the period of time indicated on packaging and for making ice cubes. • If the freezer door has been left open for a long time or not closed properly, frost may form in the freezer which can prevent efficient air circulation.
Page 23
PLACING THE FOOD Maximum Storing time Meat and fish Preparation (month) Steak Wrapping in a foil 6 - 8 Lamb meat Wrapping in a foil 6 - 8 Veal roast Wrapping in a foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes In pieces...
Page 24
PLACING THE FOOD Maximum Vegetables and Fruits Preparation Storing time (months) String beans and beans Wash, cut into small pieces and boil in water 10 - 13 Beans Hull and wash and boil in water Cabbage Cleaned and boil in water 6 - 8 Carrot Clean, cut into slices and boil in water...
Page 25
PLACING THE FOOD Maximum Storing Dairy Products Preparation Storing Conditions time (months) Packet Pure Milk – In its own In its own packet 2 - 3 (Homogenized) Milk packet Original package may be used for short storing Cheese-excluding In slices 6 - 8 period.
PART 4. CLEANING & MAINTENANCE Unplug the fridge before starting to clean it. • Do not wash your fridge by pouring water into it. • Wipe the inner and outer sides with a soft cloth or a sponge using warm and soapy water.
PART 5. SHIPMENT AND REPOSITIONING • The original packaging and foam may be kept for re-transportation (optionally). • You should fasten your fridge with thick packaging, bands or strong cords and follow the instructions for transportation on the package for re-transportation. •...
PART 6. BEFORE CALLING SERVICE Check Warnings; Your fridge warns you if the temperatures for cooler and freezer are at improper levels or when a problem occurs in the appliance. You can see these warnings on the indicator display. ERROR DISPLAY ERROR TYPE REMARK DO’s...
Page 29
BEFORE CALLING SERVICE Check Warnings: If your fridge is not operating: • Is there a power failure? • Is the plug connected to the socket correctly? • Is the fuse of the socket to which the plug is connected or the main fuse blown? •...
BEFORE CALLING SERVICE IMPORTANT NOTES: • Compressor protection function will be activated after sudden power breakdowns or after unplugging the appliance, because the gas in the cooling system is not stabilized yet. Your fridge will start after 5 minutes, there is nothing to worry about •...
PRODUCT FICHE DATA SHEET DATA SHEET: Philco Philco trademark: Brand: Philco PX 5601 NFDX Model identification Appliance type Energy efficiency class (A… low electricity consumption to G… high electricity consumption) Energy consumption over a 365 day period 1) (kWh) Total usable volume (l)
