Commissioning (via operating menu)
4.
Setup → Tank type
Select tank type.
5.
Setup → Tube diameter (only if "Tank type" = "Bypass / pipe")
Enter the diameter of the bypass or stilling well.
6.
Setup → Tank level
Select tank level (Partially filled oder Fully flooded)
7.
Setup → Distance to upper connection
In bypasses: Enter distance from reference point R to lower edge of the upper
connection; otherwise: Keep the factory setting
8.
Setup → DC value
Enter dielectric constant of the upper medium.
9.
Setup → Empty calibration
Enter the distance E between the reference point R and the minimum level (0%).
10. Setup → Full calibration
Enter distance F between the minimum (0%) and maximum (100%) level.
11. Setup → Level
Displays the measured level L
12. Setup → Interface
Displays the interface height L
13. Setup → Distance
Displays the distance D
14. Setup → Interface distance
Displays the distance D
15. Setup → Signal quality
Displays the signal quality of the level echo.
16. Setup → Mapping → Confirm distance
Compare the displayed distance to the real distance in order to start the recording
of the mapping curve.
9.7
User-specific applications
For details of setting the parameters of user-specific applications, see separate
documentation:
BA01001F (Operating Instructions FMP51/FMP52/FMP54, HART)
For the Expert submenu refer to:
GP01000F (Description of Device Parameters FMP5x, HART)
54
.
L
.
I
between the reference point R and the level L
L
between the reference point R and the interface L
I
Levelflex FMP51, FMP52, FMP54 HART
.
L
Endress+Hauser
.
I
