Levelflex FMP51, FMP52, FMP54 HART
7
Analog display device ; observe maximum load
8
Analog display device ; observe maximum load
9
Supply voltage for current output 2 (e.g. RN221N); Obeserve terminal voltage
10
Overvoltage protection module
11
Current output 2: Terminals 3 and 4
12
Terminal for the potential equalization line
13
Cable entry for current output 1
14
Cable entry for current output 2
This version is also suited for single-channel operation. In this case, current output 1
(terminals 1 and 2) must be used.
Endress+Hauser
Electrical connection
33
