Electrical connection
To remove cables from the terminal:
1. Using a flat-blade screwdriver ≤ 3 mm, press down on the slot between the two terminal
holes
2. while simultaneously pulling the cable end out of the terminal.
7.3

Post-connection check

 Is the device or cable undamaged (visual check)?
 Do the cables comply with the requirements ?
 Do the cables have adequate strain relief?
 Are all cable glands installed, securely tightened and leak-tight?
 Does the supply voltage match the specifications on the nameplate?
 Is the terminal assignment correct →  28?
 If required: Has protective ground connection been established ?
If supply voltage is present, is the device ready for operation and do values appear on the display

module?
 Are all housing covers installed and securely tightened?
 Is the securing clamp tightened correctly?
