Levelflex FMP51, FMP52, FMP54 HART
4-wire, 4-20mA HART, active
"Power supply; Output"
K: 4-wire 90-253VAC; 4-20mA HART
L: 4-wire 10,4-48VDC; 4-20mA HART
1) Feature 020 of the product structure
7.1.4 Overvoltage protection
If the measuring device is used for level measurement in flammable liquids which requires the
use of overvoltage protection according to DIN EN 60079-14, standard for
test procedures 60060-1 (10 kA, pulse 8/20 μs), an overvoltage protection module has to be
installed.
Integrated overvoltage protection module
An integrated overvoltage protection module is available for 2-wire HART as well as
PROFIBUS PA and FOUNDATION Fieldbus devices.
Product structure: Feature 610 "Accessory mounted", option NA "Overvoltage protection".
Resistance per channel
Threshold DC voltage
Threshold impulse voltage
Capacitance at 1 MHz
Nominal arrest impulse voltage (8/20 μs)
External overvoltage protection module
HAW562 or HAW569 from Endress+Hauser are suited as external overvoltage protection.
For detailed information please refer to the following documents:
• HAW562: TI01012K
• HAW569: TI01013K
7.2

Connecting the measuring device

WARNING
L
Risk of explosion!
‣
Observe applicable national standards.
‣
Comply with the specifications in the Safety Instructions (XA).
‣
Use specified cable glands only.
‣
Check to ensure that the power supply matches the information on the nameplate.
‣
Switch off the power supply before connecting the device.
‣
Connect the potential matching line to the outer ground terminal before applying the
power supply.
Endress+Hauser
1)
Terminal voltage
90 to 253 V
10.4 to 48 V
(50 to 60 Hz), overvoltage category II
AC
DC
Technical data
Electrical connection
Maximum load R
500 Ω
2 × 0.5 Ω max.
400 to 700 V
< 800 V
< 1.5 pF
10 kA
max
