Commissioning (via operating menu)
7. Setup → Empty calibration
 Enter the distance E between the reference point R and the minimum level (0%).
8. Setup → Full calibration
 Enter distance F between the minimum (0%) and maximum (100%) level.
9. Setup → Level
 Displays the measured level L.
10. Setup → Distance
 Displays the distance D between the reference point R and the level L.
11. Setup → Signal quality
 Displays the signal quality of the level echo.
12. Setup → Mapping → Confirm distance
 Compare the displayed distance to the real distance in order to start the recording
of the mapping curve
3) For FMP54 with gas phase compensation (product structure: feature 540 "Application Package", option EF or EG)
a map must NOT be recorded.
