Pair of Bentwood Chairs
Assembly Instructions - Please keep for future reference
Dimensions
Width - 45cm
Depth - 48.5cm
Height - 86.5cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:08456 400800
656/4966
656/4973
656/4980
658/7053
658/9800
Issue 2 - 22/03/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for hygena 656/4966
Summary of Contents for hygena 656/4966
- Page 1 Pair of Bentwood Chairs Assembly Instructions - Please keep for future reference 656/4966 656/4973 656/4980 658/7053 658/9800 Dimensions Width - 45cm Depth - 48.5cm Height - 86.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:08456 400800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly To ensure an easier assembly, Check you have all the Do not use this item if any we strongly advise that all fittings components and tools listed components are missing or are only finger tightened during on page 2 and 3.
-
Page 3: Components - Parts
Components - Parts Please check you have all the panels listed below Plain hole 2 Leg x 2 (65x42cm) 1 Seat pad x 2 (41x43cm) Hole with thread 3 Leg x 2 (65x42cm) - Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Attaching leg frame Assemble legs together using fixings Note: Leg has a plain hole. Leg has a threaded hole. Note: Do not fully tighten fixings at this stage. Slide spacers over ends of legs. Note: Ensure larger hole Plain hole in spacers is facing up.
- Page 6 Assembly Instructions Step 3 Arrows to point fowards Attaching seat pad Place seat pad upside down onto a clean flat surface. (edge of table top) Ensuring the arrows on the chair legs are pointing towards the front of the chair, attach leg assembly to underside of seat pad using fixings Note: Do not fully tighten...
- Page 7 Assembly Instructions Step 4 Attaching bracket After Assembly Fit bracket to chair legs using fixings Note: Do not fully tighten fixings at this stage.
- Page 8 Assembly Instructions Step 5 Tightening fixings Turn the chair upright. Whilst applying a firm downward pressure to ensure the chair is stable, fully tighten all screws. Assembly is complete. Customer helpline:08456 400800 If you need help for have damaged or missing parts, call the Home Retail Group.
- Page 9 Bentwood Chair Assembly Instructions 600/5511 - Please keep for future reference Dimensions Width - 49.5cm Depth - 49.5cm Height - 83cm Important - Please read these instructions carefully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 15/3/2011...
- Page 10 Safety and Care Advice Important - Please read these instructions carefully before starting assembly • We do not • Check you have all the • Make sure you have enough recommend the components and tools listed on space to layout the parts before use of power page 2.
- Page 11 Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check if you have all the parts listed below Seat ( LegA ( LegB ( 64 x 40 x 1.2cm) 64 x 40.5 x 1.9cm) 64 x 40.5 x 1.9cm) Components - Fittings Please check you have all the fittings listed below...
- Page 12 Assembly Instructions Step 1 Attach the legs Upside down the seat a protected table. Attach bolt with a flat washer into the center hole of seat Slide the nut plastics onto legs & as shown in the figure. Attached legs &...
