Valencia -
Assembly Instructions -
hygena
Dimensions
Width - 100cm
Depth - 34cm
Height - 72cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
1000mm Wall Cabinet
Please keep for future reference
Cabinet
Black Door Pack
Cream Door Pack
Oak Door Pack
White Gloss Door Pack
White HN Door Pack
656/5745
633/2882
633/2710
205/4009
633/2806
192/3722
MADE IN
BRITAIN
Issue 5 - 17/08/15
Advertisement
Related Manuals for hygena Valencia 1000mm Wall Cabinet
Summary of Contents for hygena Valencia 1000mm Wall Cabinet
- Page 1 Valencia - 1000mm Wall Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5745 hygena Black Door Pack 633/2882 Cream Door Pack 633/2710 Oak Door Pack 205/4009 White Gloss Door Pack 633/2806 White HN Door Pack 192/3722 Dimensions Width - 100cm...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 16.5kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base Panel (DPF097A) (969 x 319mm) 1 End Panel Loose Shelf Muntin Rail (DPF141B) (DPF098A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the left end panel Fit 2 hinge plates onto the left end panel orientated as shown. Screw 4 metal dowels into the holes shown on the left end panel Note: Tighten metal...
- Page 6 Assembly Instructions Step 3 Prepare the base and Insert 4 large locking nuts into the base and top as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 4 wooden dowels into the base and top as shown.
- Page 7 Assembly Instructions Step 4 NOTE: Hinge plates are not shown as you may have Join the right side and fitted them to the left side. base Push the base onto the right end panel Use a screwdriver to tighten the 2 large locking nuts fitted to the base...
- Page 8 Assembly Instructions Step 6 Prepare the muntin rail Tap 2 wooden dowels into the muntin rail shown. Step 7 Fit the muntin rail Attach the muntin rail to the top and base and secure with 2 screws...
- Page 9 Assembly Instructions Step 8 Fit the back Cut-outs at the top Slide the back along the grooves in the top and bottom and into the groove of the right end panel Important: Make sure that the cut-outs on the back are at the top of the assembly.
- Page 10 Assembly Instructions Step 10 18mm 18mm Fit the unit to the wall 964mm 37mm If you are joining this unit Outline of the unit to another one, also refer to step 11. To fix the unit to the wall, place the unit in the required position and lightly mark the outline of the top corners of the...
- Page 11 Assembly Instructions Step 11 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
- Page 12 Assembly Instructions Step 13 Fit the loose shelf Insert the loose shelf at an angle then lower it down onto the shelf studs Step 14 Prepare the 2 doors Push fit 2 hinges into each door Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 13 Assembly Instructions Step 15 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the doors This will be ONLY drill DO NOT drill Important: Please follow the left door these 2 holes any other holes these instructions...
- Page 14 Assembly Instructions Step 16 Fit doors and handles Note: The easiest way to attach a door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 15 Assembly Instructions Step 17 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 16 Assembly Instructions Step 18 Fit other products to the unit To fit other products to this unit, please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter. Note: Now the assembly has finished you can remove any protective film from the panels.
