Valencia -
Assembly Instructions -
hygena
Dimensions
Width - 60cm
Depth - 59cm
Height - 87cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Under Oven Cabinet
Please keep for future reference
Cabinet
Black Door Pack
Cream Door Pack
Oak Door Pack
White Gloss Door Pack
White HN Door Pack
656/5831
656/6720
656/6744
205/4281
656/6737
203/8104
MADE IN
BRITAIN
Issue 2 - 05/08/14
Advertisement
Related Manuals for hygena Valencia 656/5831
Summary of Contents for hygena Valencia 656/5831
- Page 1 Valencia - Under Oven Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5831 hygena Black Door Pack 656/6720 Cream Door Pack 656/6744 Oak Door Pack 205/4281 White Gloss Door Pack 656/6737 White HN Door Pack 203/8104 Dimensions Width - 60cm...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 16.5kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Base (DPF068A) (DPF069A) (DPF078A) (720 x 560mm) (720 x 560mm) (569 x 494mm) 5 Support Rail...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Only screw ONE metal dowel into one of these holes. Prepare the left side Screw a metal dowel into one of the holes shown on the left side Note: Tighten metal...
- Page 6 Assembly Instructions Step 3 Prepare the right side Only screw ONE metal dowel into one of these holes (use Screw a metal dowel the same hole that you used into one of the holes for the left side in step 1). shown on the right side Use the same hole that you used for the left side...
- Page 7 Assembly Instructions Step 5 Prepare the base Insert 4 large locking nuts into the base as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the base shown. Note: Wooden dowels must not stick out from the edge by more than 10mm or they may...
- Page 8 Assembly Instructions Step 7 Join the right side and base Push the base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base Note: Turn the large locking nuts as far as they will go - more than Finished 1/2 a turn.
- Page 9 Assembly Instructions Step 10 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the large locking fitted to the 2 cross rails and the 2 fitted to the base Note: Turn the large locking nuts as far as they will go - more than...
- Page 10 Assembly Instructions Step 13 Fit 2 support rails Fit a support rail flush with the support rail on the right side using 2 screws Fit a support rail flush with the support rail on the left side using 2 screws Step 14 Warning: Take care when...
- Page 11 Assembly Instructions Step 15 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
- Page 12 Assembly Instructions Step 17 Fit the appliance fascia Offer the appliance fascia up to the unit, so that it is flush with the bottom and sides of the unit. Use 2 screws screw through the brackets fitted to the support rails and into the back surface of the appliance fascia...
- Page 13 Assembly Instructions Step 19 Install the oven Please refer to the instructions that were supplied with the oven. We recommend that you contact a registered installer. Step 20 Fit other products to the unit To fit other products to this unit e.g. worktops etc., please follow the instructions packed with them.
- Page 16 ALR2659...
