Amparo Chair
Assembly Instructions
633/3252
- Please keep for future reference
633/3276
Dimensions
Width - 58cm
Depth - 49cm
Height - 75cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
Issue 1 - 02/04/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Amparo 633/3252 and is the answer not in the manual?

Questions and answers

Summary of Contents for hygena Amparo 633/3252

  • Page 1 Amparo Chair Assembly Instructions 633/3252 - Please keep for future reference 633/3276 Dimensions Width - 58cm Depth - 49cm Height - 75cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800 Issue 1 - 02/04/11...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Make sure you have enough • We do not components and tools listed on space to layout the parts before recommend the page 2.
  • Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 6400800 Please check you have all the panels listed below The quantities below are for 4 chairs Chair back x 4 Chair seat x 4 Chair leg x 4 (54.2 x 34.7 cm) (52.6 x 39.5 cm)
  • Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly of 4 chairs. In some cases more fittings may be supplied than are required. 64mm Bolt x 16 32mm Bolt x 16 28mm Bolt x 4 Nut x 4...
  • Page 5 Assembly Instructions Step 1 Assemble legs Assemble chair leg using bolt plain washer and nut Note: Do not fully tighten the bolts. Step 2 Assemble seat and back Two people are needed here a: Place chair seat upside down, put insert nuts into the holes on the underside of the seat,...
  • Page 6 Assembly Instructions Step 2 - continued Assemble chair back to the seat using bolts , spring washers and plain washer , and secure tightly by using hex key Note: Use a screwdriver to turn the insert nut slightly as shown in the figure if the bolt could not screw in.
  • Page 7 Assembly Instructions Step 2 - continued Assemble bolt cap Turn the chair to back to its up- right position, then cover the bolts on the back of the chair with bolt Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800...
