Valencia -

Assembly Instructions -

hygena

Dimensions

Width - 100cm

Depth - 59cm

Height - 87cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

1000mm Base Cabinet

Please keep for future reference

Cabinet

Black Door Pack

Cream Door Pack

Grey Door Pack

Plum Door Pack

White Door Pack

656/5790

633/2882

633/2710

656/5295

656/4540

633/2806

MADE IN

BRITAIN

Issue 1 - 16/08/11

Need help?

Do you have a question about the Valencia 656/5790 and is the answer not in the manual?

Questions and answers

Summary of Contents for hygena Valencia 656/5790

Page 1 Valencia - 1000mm Base Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5790 hygena Black Door Pack 633/2882 Cream Door Pack 633/2710 Grey Door Pack 656/5295 Plum Door Pack 656/4540 White Door Pack 633/2806 Dimensions Width - 100cm...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 26kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Base (DPF068A) (DPF069A) (DPF082A) (720 x 560mm) (720 x 560mm) (969 x 494mm) Cross Rail...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Only screw ONE metal dowel into Prepare the left side one of these holes. Screw a metal dowel into one of the holes shown on the left side If you ARE NOT fitting a sink...
Page 6 Assembly Instructions Step 3 Prepare the right side Only screw ONE metal dowel into one of these holes (use Screw a metal dowel the same hole that you used into one of the holes for the left side in step 1). shown on the right side Use the same hole that you used for the left side...
Page 7 Assembly Instructions Step 5 Prepare the base Insert 4 large locking nuts into the base 10mm as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the base shown. Note: Wooden dowels must not stick out from the edge by more than 10mm or they may...
Page 8 Assembly Instructions Step 7 Join the right side and base Push the base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
Page 9 Assembly Instructions Step 10 Prepare the muntin rail Tap 2 wooden dowels into the muntin rail shown. Step 11 Fit the muntin rail Attach the muntin rail to the base cross rail and secure with 2 screws If you are fitting a sink unit you will need to fit this support rail here Step 12...
Page 10 Assembly Instructions Step 13 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the large locking fitted to the 2 cross rails and the 2 fitted to the base Note: Turn the large locking nuts as far as they will go - more than...
Page 11 Assembly Instructions Step 15 Secure the back The bottom edge of the back must be flush with the bottom edge of the base Secure the back the back edge of the base using 4 screws Stand the unit up for the next stage.
Page 12 Assembly Instructions Step 17 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
Page 13 Assembly Instructions Step 19 Fit the unit to worktop To fit the unit to the worktop use 2 screws to screw up through the holes in the cross rail as shown. Then use 2 screws screw up through the brackets as shown.
Page 14 Assembly Instructions Step 21 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the doors Important: Please follow these instructions This will be ONLY drill carefully. the left door these 2 holes Lay the doors down...
Page 15 Assembly Instructions Step 22 Fit doors and handles 2 people are needed Push and here click Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push Push the hooks on the hinge arm underneath the front of the hinge plate...
Page 16 Assembly Instructions Step 23 Adjust the door if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
Page 17 Assembly Instructions Step 24 Fit the hinge covers Push the hinge covers onto the hinge arms Step 25 Fit the plinth After cutting the plinth to the required length, offer the plinth up to the unit Black Plinth Pack 608/2345 and using a pencil, mark the position of the unit’s Cream Plinth Pack...
Page 18 Assembly Instructions Step 26 Fit other products to the unit To fit other products to this unit e.g. worktops etc., please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter. Assembly is complete Warning: The unit is heavy.
Page 20 ALR2653...
