Space Saver Extendable TV Unit
6166560
- Please keep for future reference
hygena
Dimensions
Width - 120-228cm
Depth - 39cm
Height - 46cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Issue 1 - 21/10/16
Advertisement
Table of Contents
Related Manuals for hygena 6166560
Summary of Contents for hygena 6166560
- Page 1 Space Saver Extendable TV Unit Assembly Instructions 6166560 - Please keep for future reference hygena Dimensions Width - 120-228cm Depth - 39cm Height - 46cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, this recommend the the following pages.
- Page 3 Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below 1 Top Panel (120 x 39 x 4cm) Mid Panel (116 x 39 x 4cm) Bottom Panel (116 x 39 x 4cm) Short Side Panel x 2...
- Page 4 Assembly Instructions Step 1 Place the top panel ， mid panel bottom panel on a flat protected surface. Attaching cam bolts Insert cam bolts into holes on the top panel and mid panel shown. Attaching wood dowels Insert wood dowels into holes on the top panel , mid panel...
- Page 5 Assembly Instructions Step 2 Assembling top panel Insert cam locks Lock into holes on the short side panel as shown. Attach the top panel to short side panel aligning the cam bolts and dowels into holes as shown. Make sure the arrow on the cam locks are pointing towards the cam bolts to be able to...
- Page 6 Assembly Instructions Step 3 Assembling mid panel Insert cam locks into holes on the medium Lock side panels shown. Attach the mid panel to medium side panels by aligning the cam bolts and dowels into holes as shown. Make sure the arrow on the cam locks are pointing towards the cam bolts to be able to...
- Page 7 Assembly Instructions Step 5 Attaching adhesive pads Remove backing of adhesive pads then stick it onto the short side panels and long side panel as shown. Attaching adhesive covers Remove backing of adhesive covers then stick it onto the short side panels and medium side panels...
