Valencia - Corner Base Cabinet
Assembly Instructions -
hygena
Dimensions
Width - 88cm
Depth - 88cm
Height - 87cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
White Gloss Door Pack
Cabinet
Black Door Pack
Cream Door Pack
Oak Door Pack
White HN Door Pack
656/5800
633/2947
633/2789
204/5977
633/2868
205/3189
MADE IN
BRITAIN
Issue 2 - 05/08/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for hygena Valencia 656/5800
Summary of Contents for hygena Valencia 656/5800
- Page 1 Valencia - Corner Base Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5800 hygena Black Door Pack 633/2947 Cream Door Pack 633/2789 Oak Door Pack 204/5977 White Gloss Door Pack 633/2868 White HN Door Pack 205/3189 Dimensions Width - 88cm...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 34kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base Loose Shelf (DPF136A) (DPF137A) (800 x 800mm) x 2 (798 x 798mm) 3 Back Left/Right Side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Choose which way you would like the door to open You can fit the door to the left side or right side. If you would like your door If you would like your door to open this way, fit the...
- Page 6 Assembly Instructions Step 3 Prepare the right side Refer to step 1 and, if required, fit 2 hinge plates onto the right side , making sure that they face the same way as the diagram. Screw 4 metal dowels into the holes shown on the right side Note: Tighten metal dowels up fully against...
- Page 7 Assembly Instructions Step 5 Fit the legs to the base Push the leg sockets into the holes in the base as shown. Secure each leg socket with 3 screws Tap in the centre plug on each leg socket Push the leg into the leg socket Step 6...
- Page 8 Assembly Instructions Step 7 Prepare the back Tap 4 wooden dowels into the back shown. Step 8 Fit the back Push the back onto the base and secure with screw Step 9 Fit the top Push the top onto the right side back Use a screwdriver to tighten the 2 large...
- Page 9 Assembly Instructions Step 10 Insert the loose shelf Place the loose shelf inside the unit. Bracket Step 11 Fit the left side Push the left side onto the base Finished Use a screwdriver to front edge tighten the 4 large locking nuts fitted to the base...
- Page 10 Assembly Instructions Step 12 Fit the left back Slide the left back along the groove in the left side. Step 13 Secure the left back Secure the left back with 6 screws through its pre-drilled holes into the base and top.
- Page 11 Assembly Instructions Step 14 Fit the right back Slide the right back along the groove in the right side. Secure the right back with 6 screws through its pre-drilled holes into the base and top. Step 15 Fit the loose shelf Hold the loose shelf up and insert 7 shelf studs...
- Page 12 Assembly Instructions Step 16 Prepare 1 of the doors to be the carcase door Fit 2 hinge plates onto a door , making sure that they face the same way as the diagram. Push fit 2 cantilevered hinge arms into the door Secure each hinge arm with 2 screws Note: Before securing...
- Page 13 Assembly Instructions Step 17 Fit the carcase door Push and click 2 people are needed here Note: The easiest way to attach the carcase door is to fit the top hinge first, then align and fit the other hinge. Push the hooks on the cantilevered hinge Push underneath the...
- Page 14 Assembly Instructions Step 18 Prepare the other door to be the hinged door Push fit 2 bent hinge arms into the other door Secure each hinge arm with 2 screws Note: Before securing with the screws, make sure that the hinges are positioned at 90 degrees with the front edge of the door.
- Page 15 Assembly Instructions Step 19 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the hinged door Drill these 2 holes if you Important: Please follow have fitted the carcase these instructions door to the left side.
- Page 16 Assembly Instructions Step 20 Push and click Fit the hinged door 2 people are needed here Note: The easiest way to attach the hinged door is to fit the top hinge first, then align and fit the other hinge. Push Push the hooks on the bent hinge arm underneath the front of...
- Page 17 Assembly Instructions Step 21 Fit the soft close unit Push a soft close unit onto each cantileved hinge arm until it clicks into place.
- Page 18 Assembly Instructions Step 22 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
- Page 19 Assembly Instructions Step 23 Adjust the doors if needed Adjust the hinge plates and arms by turning the screws on them clockwise or anti- clockwise. Assembly is complete Warning: The unit is heavy. Lift with care. Step 24 Fit the plinth After cutting the plinth to the required length, offer Black Plinth Pack...
- Page 20 ALR2656...
