Inspection And Cleaning; Exterior Inspection; Exterior Cleaning - Tektronix AWG5200 Series Service Manual

Note: A lead-free solder such as SAC 305 is recommended for making repairs in this instrument. Cleaning of rosin residue is not
recommended. Most cleaning solvents tend to reactivate the rosin and spread it under components where it may cause corrosion
under humid conditions. The rosin residue, if left alone, does not exhibit these corrosive properties.

Inspection and cleaning

This section describes how to inspect for dirt and damage and how to clean the exterior of the instrument.
The instrument cover helps keep dust out of the instrument, and is needed to meet EMI and cooling requirements. The cover should be in
place when the instrument is in operation.
Inspection and cleaning, when performed regularly, may prevent the instrument from malfunctioning and enhance its reliability. Preventive
maintenance consists of visually inspecting and cleaning the instrument and using general care when operating it. How often preventive
maintenance should be performed depends on the severity of the environment in which the instrument is used. A proper time to perform
preventive maintenance is just before making any product adjustments.
Inspect and clean the instrument as often as operating conditions require.

Exterior inspection

CAUTION: Do not use chemical cleaning agents that might damage the plastics used in this instrument.
Inspect the outside of the instrument for damage, wear, and missing parts, using the following
instrument that appears to have been dropped or otherwise abused should be checked thoroughly to verify correct operation and
performance. Immediately repair defects that could cause personal injury or lead to further damage to the instrument.
Table 2: External inspection checklist
Item
Cabinet, front panel, and cover
Front-panel buttons
Connectors
Carrying handle and cabinet feet
Accessories

Exterior cleaning

To clean the exterior of the instrument, perform the following steps:
1. Blow off dust through instrument vents with dry, low-pressure, deionized air (approximately 9 psi).
2. Remove loose dust on the outside of the instrument with a lint-free cloth.
CAUTION: To prevent getting moisture inside the instrument during external cleaning, use only enough liquid to dampen the
cloth or applicator.
3. Remove remaining dirt with a lint-free cloth dampened in a general-purpose detergent and water solution. Do not use abrasive
cleaners.
AWG5200 Series Arbitrary Waveform Generators Service Manual
Inspect for
Cracks, scratches, deformations, damaged
hardware or gaskets
Missing or damaged buttons
Broken shells, cracked insulation, or
deformed contacts. Dirt in connectors
Correct operation. In this manual,
procedures refer to "front," "rear," "top," etc.
of the instrument
Missing items or parts of items, bent
pins, broken or frayed cables, or damaged
connectors
Table 2 on page 12 as a guide. An
Repair action
Send the instrument to Tektronix for service.
Send the instrument to Tektronix for service.
Send the instrument to Tektronix for service.
Repair or replace defective handle/feet
Repair or replace damaged or missing items,
frayed cables, and defective modules
Maintenance
12
