Unisab III control
Menu level 1 Menu level 2
Setup Configuration
Timers
Session
Table 7: Unisab III HMI menu tree
Engineering manual - Unisab III 1.10
001930 en 2014.09
Menu level 3
Calibration Pressure
Process temperature
Position
Frequency
Analog input
Analog output
Digital input
Digital output
Quick set up
Factory reset
Timer list (Recip./Screw)
Timer setup (Recip./Screw)
Date - Time
Oil charging (Screws only)
Motor fan (VSD only)
P band factor
Transfer (Recip. only)
Take-over (Recip. only)
Password
Serial number
Remote connect
User interface
Function Interface
E-mail
Language
25/319
Menu level 4
