Menu level 1 Menu level 2
Control values Process temp.
User
Intermediate
History Shutdown
No. of shutdowns
Table 4: Unisab III HMI menu tree
Menu level 3
Values
Process out temp. Limits
Control
Process in temp. Limits (Chiller only)
Evap. level Control (LP level control)
Condensor level Control (HP level control)
Values
User input 1 Limits
Control
Values (Two-stage recip. only)
Pressure Bar Limits
Pressure Deg. Limits
Temperature Limits
Control state
Measured values
Input state
Output state
