Set-up
No. Function
Plant
1 Refrigerant **
2 Compressor *
3 Start
4 System
5 Common evap./cond.
6 HP on two-stage
7 High limit
8 Capacity output AO1
9 Capacity down blocked
10 Take over
11 COP active
12 Chiller
13 Oil return separator
14 Oil return evaporator
15 By-pass start
16 Flow evaporator
17 Flow condenser
18 Level control
19 Ext PT100
20 Evolution
21 Flow factor
22 Liquid subcool
23 PMS feedback fixed
Oil system
1 Oil pump
2 Full flow pump
3 Oil cooling
4 Oil controller
5 Water cooling
6 Oil rectifier
7 Separator velocity reference
8 Separator velocity compres-
sion ratio
9 Separator temperature con-
trol
10 Oil low alarm coefficient
11 Oil unload coefficient
12 Oil load coefficient
Engineering manual - Unisab III 1.10
001930 en 2014.09
Set-up/Configuration
Use
1/2 Not defined, R717, R22, R502, R23, R404A,
R134A, R507, R410A, R407C, R744, R1270,
R290, R000
1/2 1-14
1/2 1-14
1/2 1-14
1/2 N/N, N/Y, Y/N, Y/Y
1/2 No, Yes
1/2 0 to 100%
1/2 No, Yes
1/2 No, Yes
1 No, Yes
1/2 No, Yes
1/2 No, Yes
1/2 No, Yes
1/2 No, Yes
1/2 No, Yes
1/2 No, Yes
1/2 No, Yes
1/2 Off/LP/HP/DX
1/2 No, Yes
1/2 No, Yes
1/2
0 to 10,000 m
1/2 0 to 99.9°C/R
1/2 No, Yes
2 No, Yes
2 No, Yes
1/2 None, Normal, HLI/BLI, Thermo pump, 3-way
valve, HLI-AKV, HLI 4-20 mA, Thermo pump
internal
2 I, PID
1 No, Yes
1/2 No, Yes
2 0.00 to 10.00
2 0.00 to 99.99
2 No, Yes
2 0.25 to 1.00 / 0.50 to 1.00
2 No, Yes
2 No, Yes
173/319
Choices
3
/hour
