Firegear PRO Series Installation And Operating Instructions Manual
Fire pit burners with all weather electronic ignition system (aws)
Hide thumbs
Also See for PRO Series:
- Installation and operating instructions manual (23 pages) ,
- Installation and operating instructions manual (18 pages) ,
- Installation and operating instructions manual (18 pages)
Table of Contents
Advertisement
Quick Links
"PRO SERIES"
Round Disc
Natural Gas Models
FPB-26DPSBR21AWS-N
FPB-29DPSBR21AWS-N
FPB-34DPSBR21AWS-N
FPB-25SFPSBR21AWS-N
FPB-30SFPSBR21AWS-N
FPB-34SFPSBR21AWS-N
All Weather Electronic Ignition System (AWS)
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This system requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation will void the warranty.
Warning: For Outdoor Use Only
Propane Gas Models
FPB-26DPSBR21AWS-P
FPB-29DPSBR21AWS-P
FPB-34DPSBR21AWS-P
FPB-25SFPSBR21AWS-P
FPB-30SFPSBR21AWS-P
FPB-34SFPSBR21AWS-P
Pro Series Fire Pit Burners with
INSTALLATION PRECAUTION:
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
26" Round Disc with 21" Pro Brass Burner
29" Round Disc with 21" Pro Brass Burner
34" Round Disc with 21" Pro Brass Burner
25" Square Disc with 21" Pro Brass Burner
30" Square Disc with 21" Pro Brass Burner
34" Square Disc with 21" Pro Brass Burner
PN#90191
Square Disc
Description
Advertisement
Table of Contents
Related Manuals for Firegear PRO Series
Summary of Contents for Firegear PRO Series
- Page 1 30” Square Disc with 21” Pro Brass Burner FPB-34SFPSBR21AWS-N FPB-34SFPSBR21AWS-P 34” Square Disc with 21” Pro Brass Burner Pro Series Fire Pit Burners with All Weather Electronic Ignition System (AWS) Installation and Operating Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS...
- Page 2 State of California to cause cancer, birth defects and other reproductive harm and Carbon Monoxide which is known to the State of California to cause birth defects or other reproductive harm. (For more information go to: www.p65Warnings.ca.gov.) FPB Pro Series Fire Pits with AWS System REV. A Page 2...
-
Page 3: Table Of Contents
Optional Accessories Warranty Congratulations! You have just purchased a Firegear Outdoors “Pro Series” fire pit that includes a 304 Stainless Steel burner pan with a Brass Burner. The Brass Burner comes in a 21-inch model. Each burner leg incorporates individual injectors that take the place of a standard main burner orifice. -
Page 4: Specifications
Btu’s. As a result your Btu’s may vary slightly from Max. Inlet 14.0” WC (½ PSI) 14.0” WC (½ PSI) Table 2 specifications. Normal Inlet 7.0” WC (¼ PSI) 11.0” WC (⅜ PSI) Table 3 Gas Pressures FPB Pro Series Fire Pits with AWS System REV. A Page 4... -
Page 5: Preparing A Non Combustible Structure
290,000 Btu’s. The system this manual for a Firegear burner. NOTE: Depending on features a built-in safety shut-off in case of flame loss and venting locations, do not place fire pit directly on grass, auto-relight. -
Page 6: Gas Pipe Sizing Chart
This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel Gas Code - current edition) for more details. Table 4 Gas Pipe Sizing Chart FPB Pro Series Fire Pits with AWS System REV. A Page 6... -
Page 7: Carton Contents - Single Fire Feature
Fig. 5. Note: Check for any gas leaks after gas is connected and turned ON. Hardware Bag (included with fire pit) Fig. 5 Hardware bag contents. FPB Pro Series Fire Pits with AWS System REV. A Page 7... -
Page 8: Pre-Installation Check List For Single Installation
- installed 10-feet or greater from a pool or spa. This power supply has a 3-foot power cord to Injectors/Jets - Fire features using a Firegear Pro Series plug into 120VAC outlet and a 3-foot leads to connect to the brass burner incorporates individual injectors/jets on each gas valve on the 30VDC side. -
Page 9: Power Supply Location For Single Installation
Fig. 7 Example of a single fire feature install with power supply and switch contained within the enclosure, when applicable. Note: Must be 10-feet or more from a pool/spa for this installation. See additional illustration on page 10, Fig. 8. FPB Pro Series Fire Pits with AWS System REV. A Page 9... -
Page 10: Burner Pan & Enclosure Preparation
Fig. 9 Shows any fire feature installed within 5 feet of a pool or spa requires FG-PS-30V320 power supply (purchased DO NOT USE THE GOE-30VDC. FG-PS-30V320 power supply can be installed up to a maximum of separately). 500-feet away from fire pit. FPB Pro Series Fire Pits with AWS System REV. A Page 10... -
Page 11: Media Installation
Do NOT cover the top of mesh pilot hood with any rock or glass. It must be free an any debris to operate properly. Mesh Pilot Hood Media Fig. 10 Media placement around pilot hood. FPB Pro Series Fire Pits with AWS System REV. A Page 11... -
Page 12: Operating- Lighting Instructions
1. Turn the fire feature OFF by pressing the OFF button of the switch or timer if applicable. 2. If you are no longer burning the fire pit until another time, we recommend turning the key valve to OFF position. FPB Pro Series Fire Pits with AWS System REV. A... -
Page 13: Replacements Parts
AWS REPLACEMENT PARTS GOE-30DCV Items are not to scale FPB Pro Series Fire Pits with AWS System REV. A Page 13... -
Page 14: Replacement Parts List & Valve Reference
½” Flare x to ½” MIP (not shown) U1-8D-S 21-inch Pro Series Brass Burner (not shown) FG-PSBR-BS21 Valve Box Reference 2-pin Igniter Connector 2-pin Thermopile Connector Flared Pilot Connection Compression Pilot Connection FPB Pro Series Fire Pits with AWS System REV. A Page 14... -
Page 15: Troubleshooting
Use a multi-meter to check resistance. Resistance should be 2.0 - 4.5 ohms. If no resistance or resistance greater than 8 ohms indicates a defective igniter. FPB Pro Series Fire Pits with AWS System REV. A... - Page 16 Thermopile is not defective the only thing left is a Defective Controller inside the valve box. If you have a Defective Controller the only way to fix it is to replace it. FPB Pro Series Fire Pits with AWS System REV. A...
- Page 17 Often this will result in a small flame that continues to burn on the Main Burner after the feature has been turned OFF. FPB Pro Series Fire Pits with AWS System REV. A Page 17...
-
Page 18: Optional Accessories
Match Throw (MT) Burning Spur fire key valve pit to use with kit listed above (sold separately). Note: See the Firegear Outdoors catalogue for a variety of fittings and flex connectors also available. FPB Pro Series Fire Pits with AWS System REV. A Page 18... -
Page 19: Warranty
FIREGEAR LIMITED WARRANTY - 2021 Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship defects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period: CONSUMER RESIDENTIAL APPLICATIONS –... - Page 20 • LIFETIME WARRANTY - CONSTRUCTION AND MANUFACTURER DEFECTS • LIFETIME WARRANTY - STAINLESS STEEL COMPONENTS (LIDS, STAINLESS STEEL COVERS) • ONE (1) YEAR WARRANTY – ESTOP1-OH, ESTOP2-5H WINDSHIELDS, HOSES AND REGULATORS FPB Pro Series Fire Pits with AWS System REV. A Page 20...
- Page 21 The manufacturer may request defective products returned with an RMA (Return Merchandise Authorization) issued by Firegear Outdoors for specific products, which is considered to be the nature of the defect and or warranty claim. Product to be returned should; be packed so as not to incur damages during transportation.
- Page 22 Firegear Outdoors 17322 Gothard St Huntington Beach, CA 92647 Web Site: www.firegearoutdoors.com Manual changes often occur, ensure to check the Firegear Outdoor website for any recent updates and warranty information. FPB Pro Series Fire Pits with AWS System REV. A...
- Page 23 Be prepared to send photos to us when on the phone. 10. Found missing or damaged parts? Let us know ASAP or send photos. Fire Pits FPB Pro Series Fire Pits with AWS System FPSS 3-30-16 REV. A Page 23...
